Be aware of the machine’s position and of your surroundings before
activating any control function.
3.3 LOWER CONTROLS
Control Description
1 Emergency Stop Press the EMERGENCY STOP at any time to stop all machine
functions.
Turn switch clockwise to reset.
2 Platform Lift/Lower Switch With the Key Switch in the LOWER position, move this switch up to
lift the platform or down to lower the platform
3 Key Switch PLATFORM - Select to operate from the PLATFORM control panel.
LOWER - Select to operate from the LOWER control panel.
OFF - Select to stop operation from either control panels.
4 Battery Indicator Indicates the state of the battery charge
5 Brake Release Switch Operate the brake release switch UP and hold to release brakes.
Release the brake release switch after use. DO NOT operate the
brake release switch if the machine is elevated or is on a sloped
surface, or if there is an operator in the platform.
1 2 3
5
HOURS
4
