GMG 1930ED - Specifications

GMG 1930ED - 4646ED
Operator’s manual
Operator’s Manual - 1930----4646ED
March 2019 #940400-3-EN
1930ED 2632ED 2646ED
HEIGHTS
Working Height
7,80 m 10,00 m 10,00 m
Platform Height
5,80 m 8,00 m 8,00 m
Stowed:
Guardrails up
2,16 m 2,29 m 2,25 m
Guardrails folded
1,79 m 1,80 m 1,69 m
Platform floor
1,03 m 1,17 m 1,04 m
Guardrail
1,10 m 1,10 m 1,10 m
Toeboard height
0,15 m 0,15 m 0,15 m
DIMENSIONS
Length
Stowed
1,82 m 2,45 m 2,46 m
With step removed
1,66 m 2,26 m 2,32 m
Width
0,76 m 0,80 m 1,17 m
Ground clearance
5 cm 10 cm 10 cm
Platform length
Extended
2,55 m 3,24 m 3,32 m
Retracted
1,64 m 2,25 m 2,31 m
Platform width
0,74 m 0,80 m 1,15 m
PERFORMANCE - GENERAL SPECIFICATIONS
Platform lift capacity
230 kg 230 kg 450 kg
Extension deck capacity
120 kg 120 kg 120 kg
Turning radius - outside
1,56 m 1,74 m 2,00 m
Power source
Batteries 24V/ 224 Ah
Drive system
Direct Electric Drive
Drive speed
Stowed
4,02 km/h
0,70 km/h
Elevated
Wheel size
14 x 4,5 inch 16 x 5 inch
Gradeability
30 % 25 %
Brakes
Multiple disc
Weight
1490 kg 2000 kg 2535 kg
Max allowable drive height
5,80 m 8,00 m 8,00 m
Max. allowable wind speed
0 m/s 0 m/s 12,5 m/s
I. SPECIFICATIONS
