Specifications
3346ED 4046ED 4646ED
HEIGHTS
Working Height
12,00 m 13,90 m 15,90 m
Platform Height
10,00 m 11,89 m 13,90 m
Stowed:
Guardrails up
2,44 m 2,55 m 2,69 m
Guardrails folded
1,76 m 1,88 m 2,00 m
Platform floor
1,31 m 1,34 m 1,60 m
Guardrail
1,10 m 1,10 m 1,10 m
Toeboard height
0,17 m 0,17 m 0,17 m
DIMENSIONS
Length
Stowed
2,46 m 2,46 m 2,46 m
With step removed
2,32 m 2,32 m 2,32 m
Width
1,17 m 1,17 m 1,17 m
Ground clearance
10 cm 10 cm 10 cm
Platform length
Extended
3,32 m 3,32 m 3,32 m
Retracted
2,31 m 2,31 m 2,31 m
Platform width
1,15 m 1,15 m 1,15 m
PERFORMANCE - GENERAL SPECIFICATIONS
Platform lift capacity
350 kg 350 kg 230 kg
Extension deck capacity
120 kg 120 kg 120 kg
Turning radius - outside
2,00 m 2,00 m 2,00 m
Power source
Direct electric drive
Drive system
24v, 225 Ah batteries
Drive speed
Stowed
3,8 km/h 3,8 km/h 3,4 km/h
Elevated
0,7 km/h
Wheel size
16 x 5 inch
Gradeability
25 %
Brakes
Multiple disc
Weight
2950 kg 3225 kg 3400 kg
Max allowable drive height
10,00 m 11,89 m 10,00 m
Max. allowable wind speed
12,5 m/s 0 m/s 0m/s
II. SPECIFICATIONS
