GMG 1930ED - 4646ED
Operator’s manual
Operator’s Manual - 1930----4646ED
March 2019 #940400-3-EN
1 Press the Platform Lock Pin Foot Pedal on the extension deck.
2 Push the platform extension guardrail to extend the platform
to the desired position.
Do not stand on the platform extension while extending or retracting it.
6.8 SHUTDOWN PROCEDURE
• When finished with the machine, place the platform in the stowed position.
• Park the machine on a level surface.
• Turn the Key Switch to the OFF position and remove the key to prevent unauthorized use. Carefully exit the platform
using a constant three (3) point dismount/grip.
• Push in the red Main Power/Lower EMERGENCY STOP Switch button to the OFF position when leaving the
m achine at the end of the work day.
• Charge the batteries.
Platform Lock Pin
Foot Pedal
IF THE ROLL-OUT DECK IS EXTENDED CHECK FOR CLEARANCE
UNDER DECK AREA BEFORE LOWERING PLATFORM.
6.7 TO EXTEND AND RETRACT THE DECK EXTENSION
