Section
3394RT---6094RT Scissor Lifts - Operator’s Manual Page 11
Control Description
1
Emergency Stop Switch
Push IN to stop all functions
Pull OUT to reset
2
Lift / Drive Selector Switch Push to the LEFT to LIFT and to the RIGHT to DRIVE
3
Horn Button Press and hold to sound warning horn
4
Engine Start Switch Push UP to start engine
5
Lights and Powered Accessory
Switch
Push DOWN to power lights and UP to power accessories
6
Engine Preheat Switch Push UP to preheat engine
7
High / Low Torque Switch
Push to the LEFT for engine high torque mode and to the RIGHT for high
speed mode
8 High / Low Engine RPM Switch
Push to the LEFT for engine low RPM
Push to the RIGHT for engine high RPM
9 FL Outrigger Switch Push UP and hold to raise the LEFT front outrigger
10 FR Outrigger Swtich Push UP and hold to raise the RIGHT front outrigger
11 Auto Level Switch
Push UP to auto level the machine and push DOWN to auto retract all 4
outriggers
12 RL Outrigger Switch Push UP and hold to raise the LEFT rear outrigger
13 RR Outrigger Switch Push UP and hold to raise the RIGHT rear outrigger
14 Joystick
Drive Controls Forward and Reverse travel
Lift
Move toward operator to ELEVATE platform. Lift speed
increases proportional to the Joystick movement.
Move away from operator to LOWER platform.
15 FL OR Indicator Light indicates that the left front outrigger is in operation
16 FR OR Indicator Light indicates that the right front outrigger is in operation
17 RR OR Indicator Light indicates that the left rear outrigger is in operation
18 RL OR Indicator Light indicates that the right rear outrigger is in operation
19 Tilt Indicator
Light indicates the machine is over the allowed tilt angle
(alarm will also sound)
20 Overload Indicator
Light indicates the machine has more than the max allowed weight on it
(alarm will also sound)
21 Elevated Height Indicator
Light indicates that the machine is past the height designating the
machine as “elevated”
22 Steer Switch
Push LEFT side of switch to steer LEFT
Push RIGHT side of switch to steer RIGHT
23 Function Enable Switch
Squeeze the top or bottom of the enable switch and hold to enable DRIVE,
LIFT, and STEER functions
4 - Component Locations
