3394RT---6094RT Scissor Lifts - Operator’s Manual Page 23
Fold Down Platform Railings
STEP 1
Remove the safety snap pins that secure the front and
rear deck extension rail panels together.
Lift the bracket connecting the tops of the deck exten-
sion rail panels.
STEP 3
Remove the safety snap pins from the deck extension
side rail bases.
Lift the deck extension side rails, pivot, and place on
the platform floor.
STEP 2
Swing the deck extension rail panels inward next to
the deck extension side rails and secure with a safety
snap pin.
9 - Fold Down Platform Railings
8 places
4 places
