3394RT---6094RT Scissor Lifts - Operator’s Manual Page 22
Deck Extension
The deck will extend in intervals of 12 inches (30 cm) throughout the entire length of the deck extension. The
extension handle hangs from the top rail at the right side of each deck extension. The handle is used to push
or pull the deck extension to the desired position.
To extend or retract the deck:
• Lift the handle to raise the spring loaded pin from the locked position.
• Push to extend or pull to retract the deck extension.
• Lower the handle enough for the spring-loaded pin to engage and continue to push or pull the deck exten-
sion until the pin locks into position.
Do not stand on the deck extension while extending or retracting it.
8 - Deck Extension
