3394RT---6094RT Scissor Lifts - Operator’s Manual Page 37
13 - Transport and Lifting Instructions
Only qualified riggers should rig and lift the machine.
Ensure that the crane capacity, loading surfaces and straps are sufficient to
withstand the machine weight. See the serial plate for the machine weight.
Process
• Fully lower the platform. Be sure the deck extension is retracted and the module doors are closed and
secure. Remove all loose items from the machine.
• Determine the center of gravity of the machine.
• Attach rigging to the designated lift points only.
• Adjust the rigging to prevent damage to the machine and to keep the machine level.
Securing to Truck or Trailer for Transport
• Lock the deck extension in the retracted position.
• Turn the key Selector Key Switch to OFF and remove the key before transport.
• Turn the Battery Disconnect Switch to OFF before transport.
• Inspect the entire machine for loose or unsecured items.
• Use chains or straps of ample load capacity.
• Use a minimum of two (2) chains or straps.
• Adjust the rigging to prevent damage to the chains and the machine.
Center of Gravity X Axis Y Axis
3394-RT 58 in. / 148 cm 69 in. / 31 cm
6094-RT 58 in. / 148 cm 69 in. / 31 cm
X
Axis
Y Axis
Lifting and Tie Down Instructions
