3394RT---6094RT Scissor Lifts - Operator’s Manual Page 33
11 - Serial Plate Description
Serial Plate Description
The serial plate is attached to the machine at the time of manufacture. Important information about the
machine is recorded on the serial plate.
Serial Plate
G
M
G
USA
xxxx
MODEL YEAR
12V
ELECT VOLT
268411
www.goGMG.com
MODEL NUMBER SERIAL NUMBER
xxxxxxxxxx6094-RT
THIS MACHINE HAS BEEN CONSTRUCTED IN ACCORDANCE WITH SECTION
4 OF ANSI/SIA A92.6-2006 AND WITH SECTION 4 OF CSA B354.4-02
MFG DATE POWER BY
xx/xxxx
3428 Bullock Lane
San Luis Obispo, California 93401 USA
DIESEL, KUBOTA
20,450 LBS (9276 kg) (EXT DECK 500 lbs (227 kg) EACH, 2 PERSONS)
MAX INCLINATION MAX. SIDE LOAD GRADEABILITY
TOTAL
MAX. PLATFORM CAPACITY INCLUDING PERSONS
1,200 lbs (545 kg) = 4 PERSONS + EQUIP.
MACHINE WEIGHT
45%90 lbs (400 N)3.0° side-side / 4.0° fore-a
MAX. LOAD PER WHEEL MAX WIND SPEED MAX. PLAT. HEIGHT
6,495 lbs (2946 kg) 60' (18.3m)28 mph (12.5 m/s)
MAX. GROUND PRESS. PER WHEEL MAX. HYD. PRESS. MAX. DRIVE HEIGHT
75.5 PSI (5.31 kg/cm²)
35' (10.7m)
4,500 PSI (310 BAR)
Item Description
MODEL NUMBER Identifies the machine.
SERIAL NUMBER
Identifies a machine with reference to its original owner. Refer to this
number when requesting information or ordering parts.
MFG DATE Month / Year of manufacture
MODEL YEAR Year of this model
POWER BY Type and manufacturer of the engine onboard.
MACHINE WEIGHT The weight of the machine with no options.
ELECT VOLT Onboard battery voltage
MAX. PLATFORM CAPACITY
INCLUDING PERSONS:
The maximum safe number of persons allowed on the platform and the
maximum safe load (persons + equipment) which can be evenly distributed
on the platform at any elevation and the maximum safe ext deck load
MAX. INCLINATION The maximum safe amount the machine can tilt side-side and fore-aft
MAX. SIDE LOAD
The maximum safe force that the occupant can exert laterally on an object
outside the platform
GRADEABILITY The maximum percent slope that the machine can safely climb
MAX. LOAD PER WHEEL The maximum safe load that can be exerted on each individual wheel
MAX. WIND SPEED The maximum safe wind speed at which the machine can be elevated
MAX. PLAT. HEIGHT
The maximum attainable height measured from level ground surface to
platform floor
MAX. GROUND PRESS.
PER WHEEL Maximum pressure each wheel exerts on the ground when fully loaded
MAX. HYD. PRESS. Maximum hydraulic system pressure during normal operation
MAX. DRIVE HEIGHT The maximum safe platform height at which the machine can be driven
