3394RT---6094RT Scissor Lifts - Operator’s Manual
Page ii
Specifications
Power
Power source Kubota Diesel Engine
Fuel tank capacity 25 gal / 95.0 L
Hydraulic system capacity 40 gal / 115.0 L
Weight
Standard
16,450 lbs
7462 kg
20,450 lbs
9276 kg
MODELS 3394-RT 6094-RT
Measurements
Working height maximum
39’ (11.9 m)
66’ (20.1 m)
Platform height maximum
33’ (10 m)
60’ (18.8 m)
3ODWIRUPKHLJKWVWRZHGSODWIRUPÀRRU
6’7” (2.02 m) 6’7” (2.02 m)
Platform length - retracted
- extended
17’5” (5.23 m)
24’10” (7.55 m)
17’5” (5.23 m)
24’10” (7.55 m)
Platform width - outside 75” (1.9 m) 75” (1.9 m)
Toeboard height
6” (15 cm)
6” (15 cm)
Height - stowed
rails lowered
122” (3.09 m)
92” (2.33 m)
128” (3.25 m)
97” (2.46 m)
Length stowed 17’ 5” (5.23 m) 17’ 5” (5.23 m)
Width 94” (2.38 m) 94” (2.38 m)
Wheelbase 113” (2.87 m) 113” (2.87 m)
Ground clearance - center 15” (38 cm) 15” (38 cm)
Productivity
Maximum platform occupancy 5 4
Lifting capacity 2,755 lbs (1250 kg) 1,200 lbs (540 kg)
Extension deck capacity (each deck) 500 lbs (227 kg) 500 lbs (227 kg)
Drive height full height 35’ (10.6 m)
Gradeability - stowed 45%
Turning radius - inside
Turning radius - outside
80” / 2.03 m
17’3” / 5.18 m
82” / 2.08 m
16.8’ / 5.12 m
Raise speed
Lower speed
36 seconds
31 seconds
60 seconds
55 seconds
Controls fully proportional
Drive four wheel
Drive speed, stowed 4.5 mph (7.2 km/h)
Drive speed, elevated 0.25 mph (0.4 km/h)
Tires - rough terrain 33 x 12 in 84 x 30 cm
