Riduttori
37
GSM_mod.MT01 IGBD 0.0
RX
Series
Industrial
8. LUBRICATION 8. SCHMIERUNG8. LUBRIFICAZIONE
8.4 Mounting positions RXO-V 8008.4 Posizioni di montaggio RXO-V 800
8.4 Einbaulagen RXO-V 800
Le quantità di olio sono approssimative; per
una corretta lubrificazione occorre fare
riferimento al livello segnato sul riduttore.
Bei den Ölmengenangaben handelt es sich
um annähernde Werte; für den Erhalt einer
korrekten Schmierung muss Bezug auf den
am Getriebe gekennzeichneten Füllstand
genommen werden.
Oil quantities specified in the table are
approximate; to ensure correct lubrication,
please refer to the level mark on the gear
unit.
Quantità di lubrificante / Lubricant Quantity / Schmiermittelmenge (l)
802 804 806 808 810 812 814 816 818 820 822 824 826 828 830
832
RXO1
RXV1
M1-M2
2,5 3,5 4,9 6,9 9,6 13,0 19,0 26,0 37,0 52,0 72,0 100,0 ————
M3
3,8 5,3 7,5 11,0 15,0 21,0 30,0 42,0 61,0 85,0 115,0 156,0 ————
M4
3,5 4,9 7,0 9,8 14,0 22,0 28,0 40,0 56,0 78,0 111,0 152,0 ————
M5-M6
3,6 5,0 7,1 10,0 14,0 20,0 29,0 40,0 57,0 79,0 110,0 151,0 ————
RXO2
RXV2
M1-M2
3,3 4,7 6,5 9,0 13,0 18,0 25,0 35,0 49,0 69,0 113,0 158,0 221,0 265,0 370,0 —
M3
6,1 8,6 12,0 17,0 24,0 34,0 48,0 68,0 95,0 133,0 201,0 285,0 400,0
a richiesta
—
M4
5,1 7,2 10,0 15,0 20,0 29,0 40,0 56,0 80,0 114,0 156,0 218,0 306,0 —
M5-M6
4,6 6,5 9,4 13,0 18,0 25,0 35,0 50,0 70,0 99,0 139,0 196,0 275,0 —
RXO3
RXV3
M1-M2
3,9 5,5 7,6 11,0 15,0 21,0 29,0 41,0 58,0 81,0 113,0 158,0 221,0 310,0 433,0 605,0
M3
8,1 11,0 15,0 22,0 32,0 44,0 62,0 87,0 125,0 175,0 246,0 345,0 485,0
a richiesta
M4
6,6 9,2 13,0 18,0 26,0 36,0 50,0 71,0 102,0 144,0 201,0 285,0 400,0
M5-M6
5,1 7,3 10,0 14,0 20,0 28,0 40,0 56,0 79,0 111,0 156,0 218,0 306,0
RXO4
M1-M2
4,9 6,4 9,5 12,8 18,8 24,4 36,3 47,6 58,0 81,0 113,0 158,0 221,0 310,0 433,0 605,0
M3
10,1 12,8 18,8 25,5 40,0 51,0 77,5 100,9 125,0 175,0 246,0 345,0 485,0
a richiesta
M4
8,3 10,7 16,3 20,9 32,5 41,8 62,5 82,4 102,0 144,0 201,0 285,0 400,0
M5-M6
7,1 9,5 14,0 18,2 28,0 36,4 56,0 72,8 79,0 111,0 156,0 218,0 306,0
