O pe n To p C ove r
Ribbon Rewind
TPH Pressure Adjust knob
Movable Media Sensor
TPH Module
TPH Module
Hook
Print Frame Hook (Right)
Print Line Adjust Knob (Right)
Ribbon Tension Adjust Knob (Right)
Print Frame Hook (Left)
Print Line Adjust Knob. (Left)
Ribbon Tension Adjust Knob. (Left)
Movable See Through Sensor
Ribbon Supply
Platen
Roller
Label Width Adjust Holder
(Left)
Paper
Damper
Label Width Adjust Holder
(Right)
