Godex RT800i Series User Manual

2. Place the cutter to align both holes of screw and then tighten the screws.
(Screw holes on the front side of the bottom barcode Printer)
3. Place the platen back to the printer and lock the clips.
4. Close the printer cover and printing mechanism.
Then to turn the printer upside down.
Tighten the screw
Screw Hole
Lock the clip
CLIP
Push
Close the printer cover
RELEASE CATCH
Release catch for closing
the printer cover

Godex RT800i Series Specifications

General

Brand	Godex
Model	RT800i Series
Category	Barcode Reader
Language	English
