10.2 HS150HH, HS200, HS200-SG, HS250 & HS300 Pumps
PUMP HS150HH HS200 HS200-SG HS250 HS300
Rotation
ACW looking at impeller from suction end
Max pump
speed
rpm
2000 1800
Max head
m (ft)
100 (328)
40 (131)
63
Max flow
m
3
/hr
(Imp.
gpm)
275 (1000) 750 (2750) 700 760 (2785) 1368
Nominal solids
capacity
Ø mm
(“)
35 (1.375) 75 (2.95) 79 75 95
Impeller
clearance (front
and rear)
mm (“)
0.50 – 0.63 (0.020 – 0.025) 0.50 – 0.63 (0.020 – 0.025)
Impeller screw
(nut) torque
Nm
(lbs.ft)
633 (467) 240
Mechanical
seal setting
dimension
mm
(ins)
34 ± 0.3 (1.339 ± 0.012)
N/A
Mechanical
seal oil
SAE 20/20 or Bioplus 46 Biodegradeable
Bearing bracket
oil
SAE 20/20
Discharge
connection
Flanged
6”ASA 150
Flanged
8”
ASA150
Flanged 8” BS10 Table D
Flanged 10”
BS10 Table D
Flanged 12”
ASA150
Hydraulic motor interface
Flange
SAE ‘D’ 4 bolt
SAE ‘C’ 4 bolt
SAE ‘D’ 4 bolt
Shaft
SAE spline 1
¾”
13 teeth
8/16DP
SAE spline 1 ¼” 12/24 DP
SAE spline 1 ¾”
13 teeth
8/16DP
14
teeth
17 teeth
Xylem Dewatering Solutions supplied motors
Drive pressure
bar
(psi)
N/A 250 (3625) 310 (4495)
Flow & Return
connection size
(supplied with quick
release couplings
on HS80, HS100 &
HS150)
1 1/4”BSPT female
Twin 1 1/2
”BSPT
female
Bearing
leakage
connection size
(supplied with quick
release couplings
on HS80, HS100 &
HS150)
½” BSPT female
3/4” BSPT
female
Pump leakage
connection size
7/8”-14 UNF
Hydraulic oil
Fluid conforming to ISO 32-46
Standard Biodegradeable
Shell Tellus Oil 27 Shell Naturelle Fluid HF-E 32
Shell Naturelle Fluid HF-E 46
Texaco Rando HD 32 or 46 Texaco Hydra 46
Texaco Rando HDZ 32 or 46 Terrasolve Envirologic 132
Max flow
l/min
@ rpm
N/A 100 @ 2000 320@1800
