10.3 HS100NC & HS150NC Pumps
PUMP
HS100NC
HS150NC
Rotation
ACW looking at impeller from suction end
Max pump speed
rpm
2200
Max head
m (ft)
40 (131)
52 (170)
Max flow
m
3
/hr (Imp.
gpm)
225 (825) 370 (1356)
Nominal solids
capacity
Ø mm (“)
35 (1.37) 42 (1.65)
Impeller clearance
(front and rear)
mm (“)
0.2mm to 0.8mm (0.008” to 0.031”)
Impeller screw
(nut) torque
Nm (lbs.ft)
76 (56)
Mechanical seal oil
N/A. Seal is fed from hydraulic system
Bearing bracket oil
N/A
Discharge
connection
4” NPT or 4” BSP 6” NPT or 6” BSP
Bearing bracket
lea
kage connection
size
3/4” NPT for NPT units or 3/8”BSPP for BSP units
Hydraulic motor interface
Flange
SAE ‘B’ 2 bolt
SAE ‘C’ 4 bolt
Shaft
SAE ‘B’ spline
13 teeth 16/32 DP
SAE ‘C’spline
14 teeth 12/24 DP
Xylem Dewatering Solutions supplied motors
Drive pressure
bar (psi)
250 (3625)
Flow & Return
connection size
3/4”BSPT female 1”BSPT female
Bearing
leakage
connection size
3/8”BSPT female 1/2”BSPT female
Pump leakage
connection size
N/A
Hydraulic oil
Fluid conforming to ISO 32-46
Standard Biodegradeable
Shell Tellus Oil 27 Shell Naturelle Fluid HF-E 32
Shell Naturelle Fluid HF-E 46
Texaco Rando HD 32 or 46 Texaco Hydra 46
Texaco Rando HDZ 32 or 46 Terrasolve Envirologic 132
Max flow
l/min @ rpm
60 @ 2000
100 @ 2000
