DESCRIPTION OF THE MONITOR
4
Description of the Tekna HF Plus monitor:
Hands-free monitor for the Plus system with button and coded panels.
n
a.
b.
c.
d.
e.
f.
g.
h.
i.
4.3” TFT colour screen
Communication with hearing aid. Set the hearing aid
switch to position T.
Function/programming buttons.
Microphone.
Brightness control.
Colour control.
Indicator LED (two-colour):
- In call: green LED illuminated.
- In communication: green LED blinking.
- Function press to talk:
When is pressed, LED illuminated yellow.
When is released, LED blinking yellow.
Advanced programming LED.
Led (bicolor) estado monitor:
-
Standby: LED illuminated red.
- Call: LED illuminated green.
j
k
-
Communication: LED illuminated green.
- Auto spy if Bus busy: LED blinking red
rapidly.
- Night mode: LED blinking red.
- Doctor mode: LED blinking green.
Connector fixings.
CN4 connector (end of line).
JP1 jumper, remove in video installation with
twisted pair (see 'EL562S module' p. 6).
RJ-45 connector (installation with UTP cable).
SW1 DIP switches.
CN2 connection terminals.
CN3 connection terminals.
Handling by authorised personnel:
Monitor microphone volume control.
Monitor speaker volume control.
j.
k.
l.
m.
n.
o.
p.
q.
r.
b
c
e
o
j
a
f
g
h
d
i
1 2 3 4 5 6 7 8 9 10
CN2
CN3
p
l
m
q
r
Description of the connection terminals:
Audio communication.
Digital communication.
Door bell button input.
Input for auxiliary door opening button.
Intercom function.
A :
D :
HZ- :
AP+ :
INT :
C 3N connection terminals:
Negative, positive (18Vdc power supply).
Video signal input through coaxial cable.
Coaxial cable mesh.
Video signal output through coaxial cable.
Balanced video signal (through twisted pair).
– :, +
Vin :
– :
Vout :
Vp, Mp :
C 2N connection terminals:
+
_
Vin
_
A D
HZ
-
MP
Vout
VP
+ SA2C A1
_
AP+
INT
Output for 2nd camera activation.
Output (negative) for auxiliary device
activation (max. consumption 50mA).
Output (negative) for auxiliary call
repeater (max. consumption 250mA).
2C
A1 :
SA :
TEKNA PLUS MONITORHF
TEKNA-HF PLUS
11742110 VXX
18121000000 SN ADDRESS
INTER A1 SLAVE MASTER
ATENCIóN
Alta tensión. No abrir la tapa.
Manipular sólo por personal
del servicio técnico.
WARNING. GOLMAR S.A.
High Voltage. Don´t open cover C/ Silici, 13
Handle only by technical service 08940 - SPAIN
ESCALERA
STAIR
PISO
FLOOR
PUERTA
DOOR
