COOLING PERFORMANCE DATA
GSC130241A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSC13024-1A* / / CA*F1824*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 23.0 23.8 26.1 - 22.4 23.3 25.5 - 21.9 22.7 24.9 - 21.4 22.1 24.3 - 20.3 21.0 23.0 - 18.8 19.5 21.4 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
Delta T 16 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 15 13 10 -
955 KW 1.63 1.66 1.71 - 1.74 1.78 1.83 - 1.84 1.88 1.94 - 1.93 1.97 2.03 - 2.01 2.05 2.11 - 2.07 2.12 2.18 -
AMPS 5.7 5.9 6.1 - 6.2 6.3 6.6 - 6.7 6.9 7.1 - 7.2 7.4 7.6 - 7.7 7.8 8.1 - 8.1 8.3 8.6 -
HI PR 139 150 159 - 157 168 178 - 178 192 202 - 203 218 230 - 228 245 259 - 252 271 286 -
LO PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -
MBh 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.3 22.0 24.1 - 20.7 21.5 23.6 - 19.7 20.4 22.4 - 18.3 18.9 20.7 -
S/T 0.71 0.59 0.41 - 0.74 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
70 849 KW 1.62 1.65 1.69 - 1.73 1.76 1.82 - 1.83 1.87 1.92 - 1.92 1.96 2.02 - 1.99 2.03 2.10 - 2.06 2.10 2.17 -
AMPS 5.7 5.8 6.0 - 6.1 6.3 6.5 - 6.7 6.8 7.1 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.0 8.2 8.5 -
HI PR 138 149 157 - 155 167 176 - 176 190 200 - 201 216 228 - 226 243 257 - 250 269 284 -
LO PR 61 65 71 - 65 69 75 - 67 71 78 - 71 75 82 - 74 79 86 - 76 81 89 -
MBh 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 19.1 19.8 21.7 - 18.2 18.9 20.7 - 16.8 17.5 19.1 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.79 0.66 0.45 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
743 KW 1.58 1.61 1.66 - 1.69 1.72 1.77 - 1.79 1.82 1.88 - 1.87 1.91 1.97 - 1.95 1.99 2.05 - 2.01 2.05 2.12 -
AMPS 5.5 5.7 5.8 - 6.0 6.1 6.3 - 6.5 6.6 6.9 - 6.9 7.1 7.3 - 7.4 7.6 7.8 - 7.8 8.0 8.3 -
HI PR 134 144 152 - 150 162 171 - 171 184 194 - 195 210 221 - 219 236 249 - 242 260 275 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 79 - 72 76 83 - 74 79 86 -
MBh 23.4 24.0 26.0 27.9 22.8 23.5 25.4 27.3 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 20.6 21.3 23.0 24.7 19.1 19.7 21.3 22.9
S/T 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
Delta T19181410191815101918151019 18 15 10 19 18 14 10 18 16 13 9
955 KW 1.64 1.67 1.72 1.77 1.76 1.79 1.84 1.90 1.86 1.90 1.95 2.01 1.95 1.99 2.05 2.11 2.02 2.07 2.13 2.20 2.09 2.14 2.20 2.27
AMPS 5.8 5.9 6.1 6.3 6.3 6.4 6.6 6.9 6.8 7.0 7.2 7.5 7.3 7.4 7.7 8.0 7.7 7.9 8.2 8.5 8.2 8.4 8.7 9.0
HI PR 141 152 160 167 158 170 180 187 180 194 204 213 205 220 233 243 230 248 262 273 255 274 289 302
LO PR 62 66 72 77 66 70 77 82 69 73 80 85 72 77 84 89 75 80 88 93 78 83 91 96
MBh 22.7 23.3 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.3 24.1 25.9 21.1 21.7 23.5 25.2 20.0 20.6 22.3 24.0 18.6 19.1 20.7 22.2
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
Delta T20181510201815102018151020 19 15 11 20 18 15 10 19 17 14 10
75 849 KW 1.63 1.66 1.71 1.76 1.74 1.78 1.83 1.89 1.84 1.88 1.94 2.00 1.93 1.97 2.03 2.10 2.01 2.05 2.11 2.18 2.07 2.12 2.18 2.25
AMPS 5.7 5.9 6.1 6.3 6.2 6.3 6.6 6.8 6.7 6.9 7.1 7.4 7.2 7.4 7.6 7.9 7.7 7.8 8.1 8.4 8.1 8.3 8.6 8.9
HI PR 140 150 159 165 157 168 178 186 178 192 202 211 203 218 230 240 228 246 259 270 252 271 286 299
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 96
MBh 20.9 21.5 23.3 25.0 20.4 21.0 22.8 24.5 20.0 20.5 22.2 23.9 19.5 20.0 21.7 23.3 18.5 19.0 20.6 22.1 17.1 17.6 19.1 20.5
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.89 0.79 0.60 0.39 0.89 0.80 0.60 0.39
Delta T20191510201915112019151121 19 16 11 20 19 15 11 19 17 14 10
743 KW 1.59 1.62 1.67 1.72 1.70 1.74 1.79 1.84 1.80 1.84 1.89 1.95 1.89 1.93 1.99 2.05 1.96 2.00 2.06 2.13 2.03 2.07 2.13 2.20
AMPS 5.6 5.7 5.9 6.1 6.0 6.2 6.4 6.6 6.5 6.7 6.9 7.2 7.0 7.2 7.4 7.7 7.4 7.6 7.9 8.2 7.9 8.1 8.4 8.7
HI PR 135 146 154 160 152 163 173 180 173 186 196 205 197 212 224 233 221 238 251 262 245 263 278 290
LO PR 60 64 70 74 63 67 74 78 66 70 76 81 69 74 80 85 72 77 84 90 75 80 87 93
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
