COOLING PERFORMANCE DATA VSC130301A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: VSC130301A* / CA*F3030*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 28.4 29.5 32.3 - 27.8 28.8 31.5 - 27.1 28.1 30.8 - 26.4 27.4 30.0 - 25.1 26.0 28.5 - 23.3 24.1 26.4 -
S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 17 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 16 13 10 -
1182 KW 1.99 2.03 2.08 - 2.13 2.17 2.23 - 2.25 2.29 2.36 - 2.36 2.40 2.48 - 2.45 2.50 2.57 - 2.53 2.58 2.66 -
AMPS 7.0 7.1 7.4 - 7.5 7.7 8.0 - 8.2 8.4 8.6 - 8.7 8.9 9.2 - 9.3 9.5 9.8 - 9.8 10.1 10.4 -
HI PR 137 148 156 - 154 166 175 - 175 188 199 - 199 215 227 - 224 241 255 - 248 267 282 -
LO PR 63 67 73 - 66 71 77 - 69 73 80 - 72 77 84 - 76 81 88 - 79 84 91 -
MBh 27.6 28.6 31.3 - 26.9 27.9 30.6 - 26.3 27.3 29.9 - 25.7 26.6 29.1 - 24.4 25.3 27.7 - 22.6 23.4 25.6 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
70 1050 KW 1.97 2.01 2.07 - 2.11 2.15 2.21 - 2.23 2.28 2.34 - 2.34 2.39 2.46 - 2.43 2.48 2.55 - 2.51 2.56 2.64 -
AMPS 6.9 7.1 7.3 - 7.5 7.6 7.9 - 8.1 8.3 8.6 - 8.6 8.9 9.1 - 9.2 9.4 9.7 - 9.7 10.0 10.3 -
HI PR 136 146 154 - 152 164 173 - 173 187 197 - 197 213 224 - 222 239 252 - 245 264 279 -
LO PR 62 66 72 - 66 70 76 - 68 73 79 - 72 76 83 - 75 80 87 - 78 83 90 -
MBh 25.5 26.4 28.9 - 24.9 25.8 28.2 - 24.3 25.2 27.6 - 23.7 24.6 26.9 - 22.5 23.3 25.6 - 20.8 21.6 23.7 -
S/T 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
919 KW 1.93 1.97 2.02 - 2.06 2.10 2.16 - 2.18 2.22 2.29 - 2.28 2.33 2.40 - 2.37 2.42 2.49 - 2.45 2.50 2.57 -
AMPS 6.7 6.9 7.1 - 7.3 7.4 7.7 - 7.9 8.1 8.3 - 8.4 8.6 8.9 - 8.9 9.2 9.5 - 9.5 9.7 10.0 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 192 206 218 - 216 232 245 - 238 256 271 -
LO PR 60 64 70 - 64 68 74 - 66 70 77 - 70 74 81 - 73 78 85 - 75 80 88 -
MBh 28.9 29.8 32.2 34.6 28.2 29.1 31.5 33.8 27.6 28.4 30.7 33.0 26.9 27.7 30.0 32.2 25.5 26.3 28.5 30.5 23.7 24.4 26.4 28.3
S/T 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.90 0.81 0.61 0.39 0.93 0.83 0.63 0.41 0.97 0.87 0.65 0.42 0.98 0.87 0.66 0.42
Delta T19181410191815101918151019 18 15 10 19 18 14 10 18 17 14 9
1182 KW 2.00 2.04 2.10 2.16 2.14 2.18 2.25 2.32 2.26 2.31 2.38 2.45 2.37 2.42 2.50 2.57 2.47 2.52 2.59 2.68 2.55 2.60 2.68 2.76
AMPS 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.2 8.4 8.7 9.0 8.8 9.0 9.3 9.7 9.4 9.6 9.9 10.3 9.9 10.2 10.5 10.9
HI PR 139 149 158 164 156 167 177 184 177 190 201 210 201 217 229 239 227 244 258 269 250 270 285 297
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 91 77 82 89 95 79 84 92 98
MBh 28.1 28.9 31.3 33.6 27.4 28.2 30.5 32.8 26.8 27.5 29.8 32.0 26.1 26.9 29.1 31.2 24.8 25.5 27.6 29.7 23.0 23.6 25.6 27.5
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.92 0.83 0.62 0.40 0.93 0.83 0.63 0.41
Delta T20181510201915102019151120 19 15 11 20 18 15 10 19 17 14 10
75 1050 KW 1.99 2.03 2.08 2.14 2.13 2.17 2.23 2.30 2.25 2.29 2.36 2.43 2.36 2.40 2.48 2.55 2.45 2.50 2.57 2.65 2.53 2.58 2.66 2.74
AMPS 7.0 7.1 7.4 7.6 7.5 7.7 8.0 8.2 8.2 8.4 8.6 9.0 8.7 8.9 9.2 9.6 9.3 9.5 9.8 10.2 9.8 10.1 10.4 10.8
HI PR 137 148 156 163 154 166 175 183 175 189 199 208 200 215 227 236 224 242 255 266 248 267 282 294
LO PR 63 67 73 78 66 71 77 82 69 73 80 85 72 77 84 90 76 81 88 94 79 84 91 97
MBh 25.9 26.7 28.9 31.0 25.3 26.0 28.2 30.3 24.7 25.4 27.5 29.5 24.1 24.8 26.8 28.8 22.9 23.6 25.5 27.4 21.2 21.8 23.6 25.4
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
Delta T20191511201915112119151121 19 16 11 20 19 15 11 19 18 14 10
919 KW 1.95 1.98 2.04 2.10 2.08 2.12 2.18 2.25 2.20 2.24 2.31 2.38 2.30 2.35 2.42 2.49 2.39 2.44 2.51 2.59 2.47 2.52 2.60 2.68
AMPS 6.8 6.9 7.2 7.4 7.3 7.5 7.7 8.0 7.9 8.1 8.4 8.7 8.5 8.7 9.0 9.3 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 194 208 220 229 218 234 247 258 241 259 273 285
LO PR 61 65 71 75 64 68 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 88 94
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
