Goodman GSC130181A User Manual

CONDENSING UNIT SPECIFICATIONS
6
GSC130181A* - GSC130181D*
GSC130241A*- GSC130301D*
GSC130[18-36]1*
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device:
MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
(3)
Installer will need to supply 3/4" to 7/8" adapters for suction line connectors
(4)
Installer will need to supply 7/8" to 1-1/8" adapters for suction line connections.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit
breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSC130181A* GSC130181BA GSC130181BB GSC130181C* GSC130181D*
Nominal Cooling Capacity, BTUH 18,000 18,000 18,000 18,000 18,000
Compressor
R.L. Amps 6.2 6.2 6.2 6.78 6.4
L.R. Amps 35 35 35 40 36
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/6 1/8
F.L. Amps 1.5 1.5 1.5 1.5 0.7
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D. 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Charge 89 81 81 67 75
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
9.3 9.3 8.9 9.98 8.7
Maximum Overcurrent Device
(2)
15 15 15 15 15
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 173 145 145 128 142
GSC130241A* GSC130241D* GSC130241E* GSC130241F* GSC130301A* GSC130301C* GSC130301D*
Nominal Cooling Capacity, BTUH 24,000 24,000 24,000 24,000 30,000 30,000 30,000
Compressor
R.L. Amps 7.7 7.8 8.0 10.8 9.7 9.7 9.7
L.R. Amps 40 40 41 56 49 49 49
Condenser Fan Motor
Horsepower 1/6 1/6 1/8 1/8 1/6 1/6 1/6
F.L. Amps 1.5 1.1 0.7 0.65 1.5 1.1 1.1
Refrigerant Line Size
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Refrigerant Connection Size
Liquid Valve Size O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Valve Size O.D. 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
3/4"
(3)
Refrigerant Charge 93 83 77 77 117 106 87
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
11.2 10.9 10.7 14.2 13.6 13.0 13.2
Maximum Overcurrent Device
(2)
15 15 15 25 20 20 20
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 195 195 142 130 195 172 172
