COOLING PERFORMANCE DATA
GSC130483B*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSC130483B* / CA*F4860*6D
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 43.1 44.7 49.0 - 42.1 43.6 47.8 - 41.1 42.6 46.7 - 40.1 41.6 45.5 - 38.1 39.5 43.3 - 35.3 36.6 40.1 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
1400 KW 2.94 3.01 3.12 - 3.20 3.28 3.40 - 3.43 3.51 3.64 - 3.63 3.72 3.86 - 3.81 3.90 4.05 - 3.96 4.06 4.21 -
AMPS 8.7 9.0 9.3 - 9.5 9.7 10.0 - 10.3 10.6 10.9 - 11.0 11.3 11.7 - 11.7 12.0 12.5 - 12.5 12.8 13.2 -
HI PR 146 158 166 - 164 177 187 - 187 201 212 - 213 229 242 - 239 258 272 - 264 285 301 -
LO PR 61 65 71 - 64 69 75 - 67 71 78 - 70 75 82 - 74 78 86 - 76 81 89 -
MBh 43.8 45.4 49.7 - 42.7 44.3 48.5 - 41.7 43.2 47.4 - 40.7 42.2 46.2 - 38.7 40.1 43.9 - 35.8 37.1 40.7 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 13 - 19 16 12 - 18 15 12 -
70 1550 KW 2.98 3.06 3.17 - 3.25 3.33 3.45 - 3.48 3.57 3.70 - 3.69 3.78 3.92 - 3.87 3.97 4.11 - 4.02 4.12 4.28 -
AMPS 8.9 9.1 9.4 - 9.6 9.9 10.2 - 10.5 10.7 11.1 - 11.2 11.5 11.9 - 11.9 12.2 12.7 - 12.7 13.0 13.4 -
HI PR 149 160 169 - 167 180 190 - 190 205 216 - 216 233 246 - 244 262 277 - 269 290 306 -
LO PR 62 66 72 - 66 70 76 - 68 72 79 - 72 76 83 - 75 80 87 - 78 83 90 -
MBh 45.1 46.7 51.2 - 44.0 45.6 50.0 - 43.0 44.5 48.8 - 41.9 43.5 47.6 - 39.8 41.3 45.2 - 36.9 38.2 41.9 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
1800 KW 3.01 3.08 3.20 - 3.28 3.36 3.48 - 3.52 3.60 3.74 - 3.73 3.82 3.96 - 3.90 4.00 4.15 - 4.06 4.16 4.32 -
AMPS 9.0 9.2 9.5 - 9.7 9.9 10.3 - 10.6 10.8 11.2 - 11.3 11.6 12.0 - 12.0 12.4 12.8 - 12.8 13.1 13.6 -
HI PR 150 162 171 - 169 182 192 - 192 207 218 - 219 235 248 - 246 265 279 - 272 292 309 -
LO PR 63 67 73 - 66 70 77 - 69 73 80 - 72 77 84 - 76 81 88 - 78 83 91 -
MBh 43.8 45.1 48.9 52.4 42.8 44.1 47.7 51.2 41.8 43.0 46.6 50.0 40.8 42.0 45.4 48.8 38.7 39.9 43.2 46.3 35.9 36.9 40.0 42.9
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
Delta T23211712232117122321171223 21 17 12 23 21 17 12 21 20 16 11
1400 KW 2.96 3.04 3.15 3.26 3.23 3.31 3.43 3.56 3.46 3.55 3.68 3.82 3.67 3.76 3.90 4.05 3.84 3.94 4.09 4.24 3.99 4.09 4.25 4.41
AMPS 8.8 9.0 9.3 9.7 9.6 9.8 10.1 10.5 10.4 10.7 11.0 11.4 11.1 11.4 11.8 12.2 11.9 12.2 12.6 13.1 12.6 12.9 13.3 13.9
HI PR 148 159 168 175 166 179 189 197 189 203 214 224 215 231 244 255 242 260 275 287 267 288 304 317
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 74 79 86 92 77 82 89 95
MBh 44.5 45.8 49.6 53.2 43.5 44.8 48.4 52.0 42.4 43.7 47.3 50.8 41.4 42.6 46.1 49.5 39.3 40.5 43.8 47.0 36.4 37.5 40.6 43.6
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
Delta T22201611222016112220161122 20 17 11 22 20 16 11 20 19 15 11
75 1550 KW 3.01 3.08 3.20 3.32 3.28 3.36 3.48 3.61 3.52 3.61 3.74 3.88 3.73 3.82 3.96 4.11 3.91 4.00 4.15 4.31 4.06 4.16 4.32 4.48
AMPS 9.0 9.2 9.5 9.9 9.7 9.9 10.3 10.7 10.6 10.8 11.2 11.6 11.3 11.6 12.0 12.4 12.1 12.4 12.8 13.3 12.8 13.1 13.6 14.1
HI PR 150 162 171 178 169 182 192 200 192 207 218 228 219 235 248 259 246 265 280 292 272 293 309 322
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
MBh 45.8 47.2 51.1 54.8 44.8 46.1 49.9 53.6 43.7 45.0 48.7 52.3 42.6 43.9 47.5 51.0 40.5 41.7 45.1 48.5 37.5 38.6 41.8 44.9
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43
Delta T20181510201915112019151120 19 15 11 20 19 15 11 19 17 14 10
1800 KW 3.04 3.11 3.23 3.35 3.31 3.39 3.52 3.65 3.55 3.64 3.77 3.92 3.76 3.86 4.00 4.15 3.94 4.04 4.19 4.35 4.10 4.20 4.36 4.52
AMPS 9.0 9.3 9.6 9.9 9.8 10.0 10.4 10.8 10.7 10.9 11.3 11.7 11.4 11.7 12.1 12.6 12.2 12.5 12.9 13.4 12.9 13.2 13.7 14.2
HI PR 152 164 173 180 171 183 194 202 194 209 220 230 221 238 251 262 248 267 282 294 275 295 312 325
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 90 77 81 89 95 79 84 92 98
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
