72
COOLING PERFORMANCE DATA VSC130241A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: VSC130241A* / CA*F1824*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 23.3 24.1 26.4 - 22.7 23.5 25.8 - 22.2 23.0 25.2 - 21.6 22.4 24.6 - 20.6 21.3 23.3 - 19.0 19.7 21.6 -
S/T 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.45 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
900 KW 1.65 1.69 1.74 - 1.77 1.81 1.87 - 1.88 1.92 1.98 - 1.97 2.02 2.08 - 2.05 2.10 2.16 - 2.12 2.17 2.24 -
AMPS 6.0 6.1 6.3 - 6.5 6.6 6.9 - 7.0 7.2 7.5 - 7.5 7.7 8.0 - 8.0 8.2 8.5 - 8.5 8.7 9.0 -
HI PR 137 148 156 - 154 166 175 - 175 189 199 - 200 215 227 - 224 242 255 - 248 267 282 -
LO PR 60 64 70 - 63 67 74 - 66 70 76 - 69 74 80 - 72 77 84 - 75 80 87 -
MBh 22.6 23.4 25.6 - 22.1 22.9 25.0 - 21.5 22.3 24.4 - 21.0 21.8 23.9 - 20.0 20.7 22.7 - 18.5 19.2 21.0 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
70 800 KW 1.64 1.67 1.72 - 1.76 1.80 1.85 - 1.87 1.90 1.96 - 1.96 2.00 2.06 - 2.04 2.08 2.15 - 2.11 2.15 2.22 -
AMPS 5.9 6.1 6.3 - 6.4 6.6 6.8 - 7.0 7.1 7.4 - 7.5 7.6 7.9 - 7.9 8.1 8.4 - 8.4 8.6 8.9 -
HI PR 136 146 154 - 152 164 173 - 173 187 197 - 198 213 224 - 222 239 253 - 246 264 279 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 80 - 72 76 83 - 74 79 86 -
MBh 20.8 21.6 23.7 - 20.4 21.1 23.1 - 19.9 20.6 22.6 - 19.4 20.1 22.0 - 18.4 19.1 20.9 - 17.1 17.7 19.4 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.70 0.58 0.41 - 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.76 0.63 0.44 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
700 KW 1.60 1.64 1.68 - 1.72 1.75 1.81 - 1.82 1.86 1.92 - 1.91 1.95 2.01 - 1.99 2.03 2.09 - 2.05 2.10 2.16 -
AMPS 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.8 7.0 7.2 - 7.3 7.4 7.7 - 7.7 7.9 8.2 - 8.2 8.4 8.7 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 192 206 218 - 216 232 245 - 238 256 271 -
LO PR 58 61 67 - 61 65 71 - 63 67 73 - 66 71 77 - 70 74 81 - 72 77 84 -
MBh 23.7 24.4 26.4 28.3 23.1 23.8 25.7 27.6 22.6 23.2 25.1 27.0 22.0 22.7 24.5 26.3 20.9 21.5 23.3 25.0 19.4 19.9 21.6 23.2
S/T 0.81 0.73 0.55 0.35 0.84 0.76 0.57 0.37 0.87 0.77 0.59 0.38 0.89 0.80 0.60 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
Delta T20181510201815102018151020 18 15 10 20 18 15 10 18 17 14 10
900 KW 1.67 1.70 1.75 1.80 1.79 1.82 1.88 1.94 1.90 1.93 1.99 2.06 1.99 2.03 2.10 2.16 2.07 2.11 2.18 2.25 2.14 2.19 2.26 2.33
AMPS 6.0 6.2 6.4 6.6 6.5 6.7 6.9 7.2 7.1 7.3 7.5 7.8 7.6 7.8 8.0 8.4 8.1 8.3 8.6 8.9 8.6 8.8 9.1 9.4
HI PR 139 149 158 164 156 167 177 184 177 190 201 210 202 217 229 239 227 244 258 269 251 270 285 297
LO PR 61 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 91 76 81 88 94
MBh 23.0 23.6 25.6 27.5 22.4 23.1 25.0 26.8 21.9 22.5 24.4 26.2 21.4 22.0 23.8 25.5 20.3 20.9 22.6 24.3 18.8 19.4 20.9 22.5
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
Delta T20191511211916112119161121 19 16 11 21 19 16 11 19 18 15 10
75 800 KW 1.65 1.69 1.74 1.79 1.77 1.81 1.87 1.92 1.88 1.92 1.98 2.04 1.97 2.02 2.08 2.15 2.05 2.10 2.16 2.23 2.12 2.17 2.24 2.31
AMPS 6.0 6.1 6.3 6.6 6.5 6.6 6.9 7.1 7.0 7.2 7.5 7.7 7.5 7.7 8.0 8.3 8.0 8.2 8.5 8.8 8.5 8.7 9.0 9.4
HI PR 137 148 156 163 154 166 175 183 175 189 199 208 200 215 227 237 224 242 255 266 248 267 282 294
LO PR 60 64 70 74 63 67 74 78 66 70 76 81 69 74 80 86 72 77 84 90 75 80 87 93
MBh 21.2 21.8 23.6 25.4 20.7 21.3 23.1 24.8 20.2 20.8 22.5 24.2 19.7 20.3 22.0 23.6 18.7 19.3 20.9 22.4 17.3 17.9 19.3 20.8
S/T 0.75 0.67 0.51 0.33 0.78 0.69 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.37
Delta T21191611211916112119161121 20 16 11 21 19 16 11 20 18 15 10
700 KW 1.62 1.65 1.70 1.75 1.73 1.77 1.82 1.88 1.84 1.87 1.93 1.99 1.93 1.97 2.03 2.09 2.00 2.05 2.11 2.18 2.07 2.12 2.18 2.25
AMPS 5.8 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.5 7.3 7.5 7.8 8.0 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 194 208 220 229 218 234 247 258 241 259 273 285
LO PR 58 62 68 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 82 87 73 77 84 90
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
