COOLING PERFORMANCE DATA
VSC130601A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: VSC130601A* / CA*F4860*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 54.9 56.9 62.3 - 53.6 55.6 60.9 - 52.3 54.2 59.4 - 51.0 52.9 58.0 - 48.5 50.3 55.1 - 44.9 46.6 51.0 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.83 0.69 0.48 -
Delta T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 17 13 - 18 15 12 -
1913 KW 3.96 4.03 4.14 - 4.23 4.31 4.43 - 4.47 4.56 4.69 - 4.68 4.77 4.92 - 4.86 4.96 5.11 - 5.01 5.12 5.27 -
AMPS 13.6 14.0 14.4 - 14.7 15.1 15.6 - 16.0 16.4 16.9 - 17.1 17.5 18.1 - 18.2 18.6 19.3 - 19.3 19.7 20.4 -
HI PR 146 157 166 - 163 176 186 - 186 200 211 - 212 228 241 - 238 256 271 - 263 283 299 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 69 73 80 - 72 76 83 - 74 79 86 -
MBh 53.3 55.2 60.5 - 52.0 53.9 59.1 - 50.8 52.7 57.7 - 49.6 51.4 56.3 - 47.1 48.8 53.5 - 43.6 45.2 49.5 -
S/T 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
70 1700 KW 3.93 4.00 4.11 - 4.20 4.28 4.40 - 4.43 4.52 4.66 - 4.64 4.74 4.88 - 4.82 4.92 5.07 - 4.98 5.08 5.23 -
AMPS 13.5 13.8 14.3 - 14.6 14.9 15.4 - 15.9 16.2 16.8 - 16.9 17.4 17.9 - 18.0 18.5 19.1 - 19.1 19.6 20.2 -
HI PR 144 155 164 - 162 174 184 - 184 198 209 - 210 226 238 - 236 254 268 - 261 280 296 -
LO PR 59 63 68 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 83 - 74 78 85 -
MBh 49.2 51.0 55.8 - 48.0 49.8 54.5 - 46.9 48.6 53.2 - 45.7 47.4 51.9 - 43.5 45.0 49.3 - 40.3 41.7 45.7 -
S/T 0.66 0.55 0.38 - 0.69 0.57 0.40 - 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.64 0.44 -
Delta T 20 17 13 - 20 18 13 - 20 18 13 - 21 18 13 - 20 18 13 - 19 16 12 -
1488 KW 3.84 3.92 4.03 - 4.11 4.18 4.30 - 4.34 4.42 4.55 - 4.54 4.63 4.77 - 4.71 4.81 4.95 - 4.86 4.96 5.11 -
AMPS 13.1 13.5 13.9 - 14.2 14.5 15.0 - 15.4 15.8 16.3 - 16.5 16.9 17.4 - 17.5 18.0 18.6 - 18.6 19.0 19.7 -
HI PR 140 151 159 - 157 169 178 - 179 192 203 - 203 219 231 - 229 246 260 - 253 272 287 -
LO PR 57 61 66 - 60 64 70 - 63 67 73 - 66 70 76 - 69 73 80 - 71 76 83 -
MBh 55.8 57.5 62.2 66.7 54.5 56.1 60.7 65.2 53.2 54.8 59.3 63.6 51.9 53.4 57.9 62.1 49.3 50.8 55.0 59.0 45.7 47.0 50.9 54.6
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41
Delta T22201711222017122220171222 21 17 12 22 20 17 12 21 19 16 11
1913 KW 3.98 4.06 4.18 4.30 4.26 4.34 4.47 4.60 4.50 4.59 4.73 4.87 4.72 4.81 4.95 5.11 4.90 5.00 5.15 5.31 5.05 5.16 5.32 5.48
AMPS 13.8 14.1 14.5 15.1 14.9 15.2 15.7 16.3 16.1 16.5 17.1 17.7 17.3 17.7 18.3 19.0 18.4 18.8 19.4 20.2 19.5 19.9 20.6 21.4
HI PR 147 158 167 174 165 178 188 196 188 202 213 223 214 230 243 254 241 259 273 285 266 286 302 315
LO PR 60 64 70 74 63 67 74 78 66 70 77 82 69 74 80 86 73 77 84 90 75 80 87 93
MBh 54.2 55.8 60.4 64.8 52.9 54.5 59.0 63.3 51.7 53.2 57.6 61.8 50.4 51.9 56.2 60.3 47.9 49.3 53.4 57.3 44.4 45.7 49.4 53.0
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
Delta T23211712232117122321171223 21 18 12 23 21 17 12 22 20 16 11
75 1700 KW 3.96 4.03 4.15 4.26 4.23 4.31 4.44 4.57 4.47 4.56 4.69 4.83 4.68 4.77 4.92 5.07 4.86 4.96 5.11 5.27 5.02 5.12 5.27 5.44
AMPS 13.6 14.0 14.4 14.9 14.7 15.1 15.6 16.2 16.0 16.4 16.9 17.6 17.1 17.5 18.1 18.8 18.2 18.6 19.3 20.0 19.3 19.8 20.4 21.2
HI PR 146 157 166 173 164 176 186 194 186 200 211 220 212 228 241 251 238 256 271 282 263 283 299 312
LO PR 59 63 69 74 63 67 73 78 65 69 76 81 69 73 80 85 72 76 83 89 74 79 86 92
MBh 50.0 51.5 55.7 59.8 48.8 50.3 54.4 58.4 47.7 49.1 53.1 57.0 46.5 47.9 51.8 55.6 44.2 45.5 49.3 52.9 40.9 42.1 45.6 49.0
S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.86 0.77 0.59 0.38
Delta T23211812242218122422181224 22 18 12 23 22 18 12 22 20 16 11
1488 KW 3.87 3.94 4.06 4.17 4.14 4.22 4.34 4.46 4.37 4.45 4.58 4.72 4.57 4.67 4.80 4.95 4.75 4.84 4.99 5.14 4.90 5.00 5.15 5.31
AMPS 13.3 13.6 14.0 14.5 14.3 14.7 15.2 15.7 15.6 15.9 16.5 17.1 16.6 17.0 17.6 18.3 17.7 18.1 18.7 19.4 18.7 19.2 19.8 20.6
HI PR 141 152 161 168 159 171 180 188 180 194 205 214 205 221 233 243 231 249 263 274 255 275 290 303
LO PR 58 61 67 71 61 65 71 75 63 67 74 78 67 71 77 82 70 74 81 86 72 77 84 89
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
