COOLING PERFORMANCE DATA
VSC130421A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: VSC130421A* / CA*F3642*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 39.7 41.1 45.1 - 38.8 40.2 44.0 - 37.8 39.2 43.0 - 36.9 38.3 41.9 - 35.1 36.4 39.8 - 32.5 33.7 36.9 -
S/T 0.76 0.63 0.44 - 0.78 0.66 0.45 - 0.80 0.67 0.47 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
1631 KW 2.74 2.79 2.87 - 2.93 2.98 3.07 - 3.09 3.15 3.24 - 3.24 3.30 3.40 - 3.36 3.43 3.53 - 3.46 3.54 3.64 -
AMPS 9.6 9.8 10.1 - 10.4 10.6 10.9 - 11.2 11.5 11.9 - 12.0 12.3 12.6 - 12.7 13.0 13.4 - 13.4 13.8 14.2 -
HI PR 142 153 161 - 159 171 181 - 181 195 206 - 206 222 234 - 232 250 264 - 256 276 291 -
LO PR 62 66 73 - 66 70 77 - 69 73 80 - 72 77 84 - 75 80 88 - 78 83 91 -
MBh 38.5 39.9 43.8 - 37.6 39.0 42.7 - 36.7 38.1 41.7 - 35.8 37.1 40.7 - 34.1 35.3 38.7 - 31.5 32.7 35.8 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -
70 1450 KW 2.72 2.77 2.85 - 2.91 2.96 3.05 - 3.07 3.13 3.22 - 3.21 3.28 3.37 - 3.33 3.40 3.50 - 3.44 3.51 3.61 -
AMPS 9.5 9.7 10.1 - 10.3 10.5 10.8 - 11.1 11.4 11.7 - 11.9 12.1 12.5 - 12.6 12.9 13.3 - 13.3 13.6 14.1 -
HI PR 141 151 160 - 158 170 179 - 179 193 204 - 204 220 232 - 230 247 261 - 254 273 288 -
LO PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -
MBh 35.6 36.9 40.4 - 34.7 36.0 39.4 - 33.9 35.1 38.5 - 33.1 34.3 37.6 - 31.4 32.6 35.7 - 29.1 30.2 33.1 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1269 KW 2.67 2.72 2.79 - 2.85 2.90 2.98 - 3.00 3.06 3.15 - 3.14 3.20 3.30 - 3.26 3.32 3.42 - 3.36 3.43 3.53 -
AMPS 9.3 9.5 9.8 - 10.0 10.2 10.6 - 10.8 11.1 11.4 - 11.5 11.8 12.2 - 12.3 12.6 13.0 - 13.0 13.3 13.7 -
HI PR 136 147 155 - 153 165 174 - 174 187 198 - 198 213 225 - 223 240 253 - 246 265 280 -
LO PR 60 64 70 - 63 67 74 - 66 70 76 - 69 74 80 - 72 77 84 - 75 80 87 -
MBh 40.4 41.6 45.0 48.3 39.4 40.6 43.9 47.2 38.5 39.6 42.9 46.0 37.5 38.7 41.8 44.9 35.7 36.7 39.7 42.7 33.0 34.0 36.8 39.5
S/T 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.91 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.88 0.67 0.43
Delta T20181510201815102018151020 18 15 10 20 18 15 10 18 17 14 10
1631 KW 2.76 2.81 2.89 2.98 2.95 3.01 3.09 3.18 3.12 3.18 3.27 3.37 3.26 3.33 3.42 3.53 3.38 3.45 3.56 3.67 3.49 3.56 3.67 3.78
AMPS 9.7 9.9 10.2 10.6 10.4 10.7 11.0 11.4 11.3 11.6 12.0 12.4 12.1 12.4 12.8 13.2 12.8 13.1 13.6 14.1 13.6 13.9 14.4 14.9
HI PR 143 154 163 170 161 173 183 191 183 197 208 217 208 224 237 247 234 252 266 278 259 279 294 307
LO PR 63 67 73 78 67 71 77 82 69 74 80 86 73 77 84 90 76 81 89 94 79 84 92 98
MBh 39.2 40.3 43.7 46.9 38.3 39.4 42.7 45.8 37.4 38.5 41.6 44.7 36.5 37.5 40.6 43.6 34.6 35.7 38.6 41.4 32.1 33.0 35.7 38.4
S/T 0.82 0.73 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.93 0.84 0.63 0.41 0.94 0.84 0.64 0.41
Delta T20191511211916112119161121 19 16 11 21 19 15 11 19 18 14 10
75 1450 KW 2.74 2.79 2.87 2.95 2.93 2.98 3.07 3.16 3.09 3.15 3.24 3.34 3.24 3.30 3.40 3.50 3.36 3.43 3.53 3.64 3.47 3.54 3.64 3.76
AMPS 9.6 9.8 10.1 10.5 10.4 10.6 10.9 11.3 11.2 11.5 11.9 12.3 12.0 12.3 12.6 13.1 12.7 13.0 13.4 13.9 13.5 13.8 14.2 14.8
HI PR 142 153 161 168 159 171 181 189 181 195 206 215 206 222 234 245 232 250 264 275 256 276 291 304
LO PR 62 66 73 77 66 70 77 82 69 73 80 85 72 77 84 89 75 80 88 93 78 83 91 97
MBh 36.2 37.2 40.3 43.3 35.3 36.4 39.4 42.3 34.5 35.5 38.4 41.2 33.6 34.6 37.5 40.2 32.0 32.9 35.6 38.2 29.6 30.5 33.0 35.4
S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
Delta T21191611211916112119161121 19 16 11 21 19 16 11 19 18 15 10
1269 KW 2.69 2.74 2.81 2.89 2.87 2.92 3.00 3.09 3.02 3.08 3.17 3.27 3.16 3.23 3.32 3.42 3.28 3.35 3.45 3.55 3.39 3.45 3.56 3.67
AMPS 9.4 9.6 9.9 10.2 10.1 10.3 10.6 11.0 10.9 11.2 11.5 12.0 11.6 11.9 12.3 12.8 12.4 12.7 13.1 13.6 13.1 13.4 13.8 14.4
HI PR 138 148 156 163 154 166 176 183 176 189 200 208 200 215 227 237 225 242 256 267 249 268 283 295
LO PR 61 64 70 75 64 68 74 79 67 71 77 82 70 74 81 86 73 78 85 91 76 81 88 94
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
