COOLING PERFORMANCE DATA
GSC130301A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSC130301A* / CAUF3131C6A
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 67715963 67 715963677159636771
MBh 28.4 29.5 32.3 - 27.8 28.8 31.5 - 27.1 28.1 30.8 - 26.4 27.4 30.0 - 25.1 26.0 28.5 - 23.3 24.1 26.4 -
S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 17 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 16 13 10 -
1182 KW 1.99 2.03 2.08 - 2.13 2.17 2.23 - 2.25 2.29 2.36 - 2.36 2.40 2.48 - 2.45 2.50 2.57 - 2.53 2.58 2.66 -
AMPS 7.0 7.1 7.4 - 7.5 7.7 8.0 - 8.2 8.4 8.6 - 8.7 8.9 9.2 - 9.3 9.5 9.8 - 9.8 10.1 10.4 -
HI PR 142 153 162 - 160 172 182 - 182 196 206 - 207 223 235 - 233 251 265 - 257 277 292 -
LO PR 64 68 74 - 67 71 78 - 70 74 81 - 73 78 85 - 77 82 89 - 79 84 92 -
MBh 27.6 28.6 31.3 - 26.9 27.9 30.6 - 26.3 27.3 29.9 - 25.7 26.6 29.1 - 24.4 25.3 27.7 - 22.6 23.4 25.6 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
70 1050 KW 1.97 2.01 2.07 - 2.11 2.15 2.21 - 2.23 2.28 2.34 - 2.34 2.39 2.46 - 2.43 2.48 2.55 - 2.51 2.56 2.64 -
AMPS 6.9 7.1 7.3 - 7.5 7.6 7.9 - 8.1 8.3 8.6 - 8.6 8.9 9.1 - 9.2 9.4 9.7 - 9.7 10.0 10.3 -
HI PR 141 152 160 - 158 170 180 - 180 194 204 - 205 220 233 - 231 248 262 - 255 274 289 -
LO PR 63 67 73 - 66 71 77 - 69 73 80 - 73 77 84 - 76 81 88 - 79 84 91 -
MBh 25.5 26.4 28.9 - 24.9 25.8 28.2 - 24.3 25.2 27.6 - 23.7 24.6 26.9 - 22.5 23.3 25.6 - 20.8 21.6 23.7 -
S/T 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
919 KW 1.93 1.97 2.02 - 2.06 2.10 2.16 - 2.18 2.22 2.29 - 2.28 2.33 2.40 - 2.37 2.42 2.49 - 2.45 2.50 2.57 -
AMPS 6.7 6.9 7.1 - 7.3 7.4 7.7 - 7.9 8.1 8.3 - 8.4 8.6 8.9 - 8.9 9.2 9.5 - 9.5 9.7 10.0 -
HI PR 137 147 155 - 153 165 174 - 175 188 198 - 199 214 226 - 224 241 254 - 247 266 281 -
LO PR 61 65 71 - 64 69 75 - 67 71 78 - 70 75 82 - 74 78 86 - 76 81 89 -
MBh 28.9 29.8 32.2 34.6 28.2 29.1 31.5 33.8 27.6 28.4 30.7 33.0 26.9
27.7
30.0 32.2 25.5 26.3 28.5 30.5 23.7 24.4 26.4 28.3
S/T 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.90 0.81 0.61 0.39 0.93
0.83
0.63 0.41 0.97 0.87 0.65 0.42 0.98 0.87 0.66 0.42
Delta T191814101918151019 18 151019
18
15 10 19 18 14 10 18 17 14 9
1182 KW 2.00 2.04 2.10 2.16 2.14 2.18 2.25 2.32 2.26 2.31 2.38 2.45 2.37
2.42
2.50 2.57 2.47 2.52 2.59 2.68 2.55 2.60 2.68 2.76
AMPS 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.2 8.4 8.7 9.0 8.8
9.0
9.3 9.7 9.4 9.6 9.9 10.3 9.9 10.2 10.5 10.9
HI PR 144 155 163 170 161 174 183 191 184 198 209 218 209
225
238 248 235 253 267 279 260 280 295 308
LO PR 64 68 75 79 68 72 79 84 70 75 82 87 74
79
86 92 78 83 90 96 80 85 93 99
MBh 28.1 28.9 31.3 33.6 27.4 28.2 30.5 32.8 26.8 27.5 29.8 32.0 26.1
26.9
29.1 31.2 24.8 25.5 27.6 29.7 23.0 23.6 25.6 27.5
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.37 0.89
0.79
0.60 0.39 0.92 0.83 0.62 0.40 0.93 0.83 0.63 0.41
Delta T201815102019151020 19 151120
19
15 11 20 18 15 10 19 17 14 10
75 1050 KW 1.99 2.03 2.08 2.14 2.13 2.17 2.23 2.30 2.25 2.29 2.36 2.43 2.36
2.40
2.48 2.55 2.45 2.50 2.57 2.65 2.53 2.58 2.66 2.74
AMPS 7.0 7.1 7.4 7.6 7.5 7.7 8.0 8.2 8.2 8.4 8.6 9.0 8.7
8.9
9.2 9.6 9.3 9.5 9.8 10.2 9.8 10.1 10.4 10.8
HI PR 142 153 162 169 160 172 182 189 182 196 207 215 207
223
235 245 233 251 265 276 257 277 292 305
LO PR 64 68 74 79 67 71 78 83 70 74 81 86 73
78
85 91 77 82 89 95 79 85 92 98
MBh 25.9 26.7 28.9 31.0 25.3 26.0 28.2 30.3 24.7 25.4 27.5 29.5 24.1
24.8
26.8 28.8 22.9 23.6 25.5 27.4 21.2 21.8 23.6 25.4
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86
0.77
0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
Delta T201915112019151121 19 151121
19
16 11 20 19 15 11 19 18 14 10
919 KW 1.95 1.98 2.04 2.10 2.08 2.12 2.18 2.25 2.20 2.24 2.31 2.38 2.30
2.35
2.42 2.49 2.39 2.44 2.51 2.59 2.47 2.52 2.60 2.68
AMPS 6.8 6.9 7.2 7.4 7.3 7.5 7.7 8.0 7.9 8.1 8.4 8.7 8.5
8.7
9.0 9.3 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5
HI PR 138 149 157 164 155 167 176 184 176 190 200 209 201
216
228 238 226 243 257 268 250 269 284 296
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71
76
83 88 74 79 87 92 77 82 89 95
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
