COOLING PERFORMANCE DATA
GSC130361D*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSC130361D* / CAUF3636B6A
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 677159 63 67715963677159636771
MBh 34.3 35.5 38.9 - 33.5 34.7 38.0 - 32.7 33.9 37.1 - 31.9 33.1 36.2 - 30.3 31.4 34.4 - 28.1 29.1 31.9 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
1350 KW 2.40 2.44 2.52 - 2.57 2.62 2.70 - 2.72 2.78 2.86 - 2.85 2.91 3.00 - 2.97 3.03 3.13 - 3.07 3.13 3.23 -
AMPS 8.6 8.8 9.1 - 9.3 9.5 9.9 - 10.1 10.4 10.7 - 10.8 11.1 11.5 - 11.5 11.8 12.2 - 12.2 12.5 13.0 -
HI PR 142 153 161 - 159 171 181 - 181 195 206 - 206 222 234 - 232 250 264 - 256 276 291 -
LO PR 62 66 72 - 66 70 76 - 68 73 79 - 72 76 83 - 75 80 87 - 78 83 90 -
MBh 33.3 34.5 37.8 - 32.5 33.7 36.9 - 31.7 32.9 36.1 - 31.0 32.1 35.2 - 29.4 30.5 33.4 - 27.3 28.3 31.0 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.79 0.66 0.46 -
Delta T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -
70 1200 KW 2.38 2.43 2.50 - 2.55 2.60 2.68 - 2.70 2.76 2.84 - 2.83 2.89 2.98 - 2.95 3.01 3.10 - 3.04 3.11 3.21 -
AMPS 8.5 8.7 9.0 - 9.2 9.5 9.8 - 10.0 10.3 10.6 - 10.7 11.0 11.4 - 11.4 11.7 12.1 - 12.1 12.4 12.8 -
HI PR 141 151 160 - 158 170 179 - 179 193 204 - 204 220 232 - 230 247 261 - 254 273 289 -
LO PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -
MBh 30.7 31.9 34.9 - 30.0 31.1 34.1 - 29.3 30.4 33.3 - 28.6 29.6 32.5 - 27.2 28.2 30.8 - 25.2 26.1 28.6 -
S/T 0.67 0.56 0.38 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1050 KW 2.33 2.37 2.44 - 2.49 2.54 2.62 - 2.64 2.69 2.77 - 2.77 2.82 2.91 - 2.88 2.94 3.03 - 2.97 3.03 3.13 -
AMPS 8.3 8.5 8.8 - 9.0 9.2 9.5 - 9.8 10.0 10.3 - 10.4 10.7 11.0 - 11.1 11.4 11.8 - 11.8 12.1 12.5 -
HI PR 136 147 155 - 153 165 174 - 174 187 198 - 198 213 225 - 223 240 253 - 246 265 280 -
LO PR 60 64 69 - 63 67 73 - 66 70 76 - 69 73 80 - 72 77 84 - 75 80 87 -
MBh 34.9 35.9 38.9 41.7 34.1 35.1 38.0 40.7 33.3 34.2 37.1 39.8 32.4 33.4 36.2 38.8 30.8 31.7 34.4 36.9 28.6 29.4 31.8 34.2
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
Delta T201815102018151020 18 151020 18 15 10 20 18 15 10 18 17 14 10
1350 KW 2.41 2.46 2.54 2.61 2.59 2.64 2.72 2.80 2.74 2.80 2.88 2.98 2.88 2.94 3.03 3.13 2.99 3.06 3.15 3.25 3.09 3.16 3.26 3.36
AMPS 8.7 8.9 9.2 9.5 9.4 9.6 9.9 10.3 10.2 10.5 10.8 11.2 10.9 11.2 11.6 12.0 11.6 11.9 12.3 12.8 12.3 12.6 13.1 13.6
HI PR 143 154 163 170 161 173 183 191 183 197 208 217 208 224 237 247 234 252 266 278 259 279 294 307
LO PR 63 67 73 78 66 71 77 82 69 74 80 85 73 77 84 90 76 81 88 94 79 84 91 97
MBh 33.9 34.9 37.7 40.5 33.1 34.1 36.9 39.6 32.3 33.2 36.0 38.6 31.5 32.4 35.1 37.7 29.9 30.8 33.3 35.8 27.7 28.5 30.9 33.2
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.81 0.61 0.39
Delta T201915112119161121 19 161121 19 16 11 20 19 15 11 19 18 14 10
75 1200 KW 2.40 2.44 2.52 2.59 2.57 2.62 2.70 2.78 2.72 2.78 2.86 2.95 2.85 2.91 3.01 3.10 2.97 3.03 3.13 3.23 3.07 3.13 3.23 3.34
AMPS 8.6 8.8 9.1 9.4 9.3 9.5 9.9 10.2 10.1 10.4 10.7 11.1 10.8 11.1 11.5 11.9 11.5 11.8 12.2 12.7 12.2 12.5 13.0 13.5
HI PR 142 153 161 168 159 171 181 189 181 195 206 215 206 222 235 245 232 250 264 275 257 276 292 304
LO PR 62 66 72 77 66 70 76 81 68 73 79 85 72 76 83 89 75 80 87 93 78 83 90 96
MBh 31.3 32.2 34.8 37.4 30.5 31.4 34.0 36.5 29.8 30.7 33.2 35.6 29.1 29.9 32.4 34.8 27.6 28.4 30.8 33.0 25.6 26.3 28.5 30.6
S/T 0.76 0.68 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
Delta T211916112119161121 19 161121 19 16 11 21 19 16 11 19 18 15 10
1050 KW 2.34 2.39 2.46 2.53 2.51 2.56 2.64 2.72 2.66 2.71 2.79 2.88 2.79 2.85 2.93 3.03 2.90 2.96 3.05 3.15 2.99 3.06 3.15 3.25
AMPS 8.4 8.6 8.9 9.2 9.1 9.3 9.6 9.9 9.8 10.1 10.4 10.8 10.5 10.8 11.1 11.6 11.2 11.5 11.9 12.3 11.9 12.2 12.6 13.1
HI PR 138 148 157 163 155 166 176 183 176 189 200 208 200 215 227 237 225 242 256 267 249 268 283 295
LO PR 60 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 90 76 80 88 93
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
