COOLING PERFORMANCE DATA
GSC130481B*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSC130481B* / CA*F4860*6D*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159 63 67715963 67715963677159636771
MBh 44.6 45.6 48.7 52.1 43.6 44.5 47.6 50.9 42.5 43.5 46.4 49.6 41.5 42.4 45.3 48.4 39.4 40.3 43.0 46.0 36.5 37.3 39.9 42.6
S/T 0.860.810.660.490.900.840.680.510.92 0.86 0.700.520.95 0.89 0.720.540.980.920.750.560.990.930.760.57
Delta T252421172625211726 25 211726 25 22172524211724232016
1400 KW 2.99 3.06 3.18 3.29 3.26 3.34 3.46 3.59 3.49 3.58 3.71 3.85 3.70 3.80 3.94 4.08 3.88 3.98 4.12 4.28 4.03 4.13 4.29 4.45
AMPS 12.8 13.1 13.6 14.1 13.9 14.2 14.7 15.2 15.1 15.5 16.0 16.6 16.2 16.6 17.1 17.8 17.2 17.6 18.2 19.0 18.3 18.7 19.4 20.1
HI PR 149 161 170 177 168 180 190 199 191 205 217 226 217 234 247 257 244 263 278 290 270 290 307 320
LO PR 62 66 72 77 66 70 76 81 68 73 79 85 72 76 83 89 75 80 87 93 78 83 90 96
MBh 45.3 46.3 49.5 52.9 44.2 45.2 48.3 51.6 43.2 44.1 47.2 50.4 42.1 43.1
46.0
49.2 40.0 40.9 43.7 46.7 37.1 37.9 40.5 43.3
S/T 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.98 0.92
0.75
0.56 1.00 0.96 0.78 0.58 1.00 0.96 0.78 0.59
Delta T242320162423201624 23 201625 24
20
16 24 23 20 16 22 22 19 15
80 1550 KW 3.04 3.11 3.23 3.35 3.31 3.39 3.52 3.65 3.55 3.64 3.77 3.92 3.76 3.86
4.00
4.15 3.94 4.04 4.19 4.35 4.10 4.20 4.36 4.52
AMPS 13.0 13.3 13.8 14.3 14.1 14.4 14.9 15.5 15.3 15.7 16.3 16.9 16.4 16.8
17.4
18.1 17.5 17.9 18.5 19.3 18.6 19.0 19.7 20.4
HI PR 152 164 173 180 171 184 194 202 194 209 220 230 221 238
251
262 248 267 282 295 275 295 312 325
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78
85
90 77 81 89 95 79 84 92 98
MBh 46.7 47.7 50.9 54.4 45.6 46.6 49.7 53.2 44.5 45.5 48.6 51.9 43.4 44.3 47.4 50.6 41.2 42.1 45.0 48.1 38.2 39.0 41.7 44.6
S/T 0.940.880.720.541.000.910.740.561.00 0.94 0.760.571.00 0.97 0.790.591.001.000.820.611.001.000.820.62
Delta T222119152322191523 22 191522 22 19152122191520201814
1800 KW 3.07 3.14 3.26 3.38 3.34 3.42 3.55 3.68 3.58 3.67 3.81 3.95 3.80 3.89 4.04 4.19 3.98 4.08 4.23 4.39 4.14 4.24 4.40 4.57
AMPS 13.1 13.5 13.9 14.4 14.2 14.6 15.1 15.6 15.5 15.9 16.4 17.0 16.6 17.0 17.6 18.2 17.7 18.1 18.7 19.5 18.7 19.2 19.9 20.6
HI PR 153 165 174 182 172 185 196 204 196 211 223 232 223 240 254 264 251 270 285 297 277 298 315 329
LO PR 64 68 74 79 68 72 78 84 70 75 82 87 74 78 86 91 77 82 90 96 80 85 93 99
MBh 45.4 46.3 48.5 51.7 44.3 45.2 47.3 50.5 43.3 44.1 46.2 49.3 42.2 43.0 45.1 48.1 40.1 40.9 42.8 45.7 37.2 37.9 39.7 42.3
S/T 0.910.870.790.640.940.910.820.660.96 0.93 0.840.680.99 0.96 0.870.701.000.990.900.731.001.000.910.73
Delta T272725222727252227 27 252228 27 26222627252224252420
1400 KW 3.02 3.09 3.21 3.32 3.29 3.37 3.49 3.62 3.53 3.61 3.75 3.89 3.74 3.83 3.97 4.12 3.92 4.01 4.16 4.32 4.07 4.17 4.33 4.49
AMPS 12.9 13.2 13.7 14.2 14.0 14.3 14.8 15.4 15.2 15.6 16.1 16.8 16.3 16.7 17.3 17.9 17.4 17.8 18.4 19.1 18.4 18.9 19.5 20.3
HI PR 151 162 171 179 169 182 192 201 193 207 219 228 219 236 249 260 247 265 280 292 273 293 310 323
LO PR 63 67 73 78 66 71 77 82 69 73 80 85 72 77 84 90 76 81 88 94 79 84 91 97
MBh 46.1 47.0 49.2 52.5 45.0 45.9 48.1 51.3 43.9 44.8 46.9 50.1 42.9 43.7 45.8 48.8 40.7 41.5 43.5 46.4 37.7 38.5 40.3 43.0
S/T 0.940.910.820.660.970.940.850.691.00 0.96 0.870.711.00 0.99 0.900.731.001.000.930.761.001.000.940.76
Delta T262524212626242126 26 242125 26 24212425242122232219
85 1550 KW 3.07 3.14 3.26 3.38 3.34 3.42 3.55 3.68 3.58 3.67 3.81 3.95 3.80 3.89 4.04 4.19 3.98 4.08 4.23 4.39 4.14 4.24 4.40 4.57
AMPS 13.1 13.5 13.9 14.4 14.2 14.6 15.1 15.6 15.5 15.9 16.4 17.0 16.6 17.0 17.6 18.2 17.7 18.1 18.7 19.5 18.7 19.2 19.9 20.6
HI PR 153 165 174 182 172 185 196 204 196 211 223 232 223 240 254 264 251 270 285 297 277 298 315 329
LO PR 64 68 74 79 68 72 78 84 70 75 82 87 74 78 86 91 77 82 90 96 80 85 93 99
MBh 47.5 48.4 50.7 54.1 46.4 47.3 49.5 52.8 45.3 46.1 48.3 51.6 44.2 45.0 47.1 50.3 42.0 42.8 44.8 47.8 38.9 39.6 41.5 44.3
S/T 0.980.950.860.701.000.980.890.721.00 1.00 0.910.741.00 1.00 0.940.761.001.000.980.791.001.000.980.80
Delta T242322192424221923 24 221923 23 23202122221920202118
1800 KW 3.09 3.17 3.29 3.41 3.37 3.46 3.58 3.72 3.62 3.71 3.85 3.99 3.83 3.93 4.08 4.23 4.02 4.12 4.27 4.43 4.18 4.28 4.44 4.61
AMPS 13.3 13.6 14.0 14.6 14.4 14.7 15.2 15.8 15.6 16.0 16.6 17.2 16.7 17.1 17.7 18.4 17.8 18.3 18.9 19.6 18.9 19.4 20.1 20.8
HI PR 155 167 176 184 174 187 198 206 198 213 225 234 225 242 256 267 253 273 288 300 280 301 318 332
LO PR 65 69 75 80 68 73 79 84 71 75 82 88 74 79 87 92 78 83 91 97 81 86 94 100
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions
