Tighten the screw connection. Then the terminal can be connected to the
inverterside.
Compressthetwosnap‐inspringsbyhandandrelease.
DSpecificationsofthe DCwires
The cable are used outdoor that must comply with PV cable standards, as
TUV 2Pfg1169, Type PV1‐F, 600V, 90℃ wet. The wire diameters should be
2.5‐6mm
2
.
Remark: The solar energy system often works under harsh environmental
conditions,suchashightemperatureandultravioletradiation.Therefore,the
solar system and photovoltaic array must be connected using a specialist
photovoltaicelectriccableastheDCcable.
Caution!
` RegardingtheinverterequippedwithDCswitch,pleaseensuretheswitch
is in "OFF" position before connecting the inverter with PV panels. Then
switchto"ON"whenfinishedconnectingjob.
` BeforeconnectingthePVpanels,pleaseensuretheplugconnectorshave
the correct polarity. Incorrect polarity connection could permanently
