A double level play set could use three Canopy Accents. One on the lower level front center post and two on
Note: The Canopy Accent is sold individually with two screws. A single level play set such as the one shown
CANOPY ACCENT (07-0032)
the upper level front and rear center posts.
post.
below could use two Canopy Accents. One may be placed on the front center post as well as the rear center
1: Center the Canopy Accent over the front or rear center post. The top of the Canopy Accent should be
flush to the top of the center tarp board.
2: Install two #8 x 1-3/4" wood screws to secure the Canopy Accent to the front or rear center post.
*SOLD SEPARATELY**SOLD SEPARATELY*
Purchase two Canopy
Accents if you want one
on the rear center post.
A
DETAIL A
SCALE 1 : 7
Canopy Accent
#8 X 1-3/4"
Wood Screws
*FOR RESIDENTIAL USE ONLY*
*FOR CHILDREN AGES 3-11*
2
2
"
84.00°
16
"
9
4"
1
2
3
16
"
"
3
4
10"
