Gorilla Treasure Trove II User Manual

STEP 37: RAILING
1: PLACE THE 2 X 4 X 70" REAR TOP PANEL BOARD (RAILING) OFFSET UP INSIDE THE LAG
POSTS OF THE UPPER LEVEL.
2: THE TOP OF THE RAILING SHOULD BE 33" ABOVE THE DECK BOARDS.
3: ATTACH THE RAILING TO THE LAG POSTS AND UPPER LEVEL CENTER POST WITH 5/16" X
3-1/2" LAG SCREWS WITH 5/16" WASHERS.
LAG SCREW
(OFFSET UP)
5/16" WASHER
REAR TOP PANEL BOARD
2 X 4 X 70"
5/16" X 3-1/2"
NOTE: SOME RAILINGS
REMOVED FROM PICTURE
FOR CLARITY.
33"
82
