Gorilla Treasure Trove II User Manual

2: FASTEN THE 2 X 4 X 70" DECK SUPPORTS TO THE HOLES AT 54-3/4" WITH 5/16 X 4-1/2" HEX
FRONT OF FORT
STEP 5: DECK SUPPORTS
BOLTS AND 5/16" WASHERS FROM THE INSIDE OF THE FORT
YOU WILL NEED AN EXTRA PERSON FOR THIS STEP.
1: WITH HELP, STAND UP THE LEFT AND RIGHT SIDE ASSEMBLIES.
2 X 4 X 70"
DECK SUPPORT
WASHER
5/16"
FRAME
LEFT SIDE FRAME
SIDE
5/16" X 4-1/2"
HEX BOLT
RIGHT
(2 HOLES ON CENTER)
HOLES FOR
CLATTER-BRIDGE
CHAINS
50
