Gorilla Treasure Trove II User Manual

5/16 X 3-1/2"
5/16" WASHER
LAG SCREW
REAR OF
TOWER
2 X 4 X 36-3/4"
SAFETY BOARD
WITH CHAIN
HOLES
A
C
B
STEP 11: REAR BOTTOM PANEL BOARD
D
1: PLACE THE 2 X 4 X 36-3/4" SAFETY BOARD WITH CHAIN HOLES AGAINST THE REAR CORNER POSTS, AND LEVEL
THE TOP OF THE BOARD WITH THE TOP OF THE DECK BOARDS.
2: FASTEN THE SAFETY BOARD TO THE CORNER POSTS WITH 5/16 X 3-1/2" LAG SCREWS WITH 5/16" WASHERS.
129
