A
STEP 71: GROUND STAKES
1: HAMMER A GROUND STAKE INTO THE EARTH NEXT TO EACH SWING LEG AT AN ANGLE. DO
NOT HOLD THE UPPER PORTION OF THE STAKE AFTER THE FIRST COUPLE OF HITS OR IT MAY
VIBRATE HARSHLY AGAINST YOUR HAND. IF THE TOP PART OF THE STAKE TWISTS WHEN IT
ENCOUNTERS A ROCK OR ROOT YOU MAY HAVE TO BEND THE TOP PORTION OF THE STAKE
AGAINST THE SWING LEG. FINALLY INSTALL THE SCREW AND WASHER.
2: ATTACH EACH GROUND STAKE TO THE SWING LEG WITH A #14 X 2" PAN HEAD SCREW AND
A 1/4" FENDER WASHER PROVIDED WITH THE GROUND STAKE.
DETAIL A
SCALE 1 : 6
STAKE
PAN HEAD SCREW
#14 x 2"
GROUND
1/4" FENDER WASHER
