Gorilla Treasure Trove II User Manual

5/4 X 3 X 28-1/2"
PANEL SLAT
5
"
1"
16
1"
"
16
1
5
1
2X
1
8
"
RIGHT SIDE VIEW OF SLATS.
2
1
2"
2
7
8
"BETWEEN SLATS
D
B
STEP 12: PANEL SLATS
A
4: ATTACH THE PANEL SLATS WITH 2" WOOD SCREWS IN THE PRE-DRILLED HOLES TO THE RIGHT SIDE OF THE TOWER.
1: FIND TEN 5/4 X 3 X 28-1/2" PANEL SLATS.
2: PRE-DRILL THE PANEL SLATS 1" FROM EACH END ON CENTER WITH A 1/8" DRILL BIT. (SEE TOP LEFT PICTURE
BELOW)
3: INSTALL THE FIRST PANEL SLAT 2-1/2" FROM THE CORNER POST. THEN INSTALL THE REMAINING FOUR PANEL SLATS
2-7/8" APART AS SHOWN IN THE PICTURE AT THE BOTTOM LEFT BELOW.
C
TOWER
FRONT OF
RIGHT SIDE
OF TOWER
SHOWN FOR
2" WOOD SCREW.
CLARITY.
CORNER POST
"A" AND
OTHER
BOARDS NOT
ATTACH 5 SLATS
ON THIS SIDE ALSO.
