STEP 40: UPPER LEVEL REAR CENTER POST
1: PLACE THE 2 X 4 X 69-5/8" UPPER LEVEL REAR CENTER POST AGAINST THE REAR RAILING
ON THE UPPER LEVEL. HAMMER A T-NUT INTO THE TOP HOLE IN THE UPPER LEVEL REAR
CENTER POST. LINE UP THE HOLE IN THE UPPER LEVEL REAR CENTER POST WITH THE HOLE
IN THE REAR RAILING.
2: ATTACH THE UPPER LEVEL CENTER POST TO THE RAILING AT THE TOP WITH A 5/16" X 2-
1/2" HEX BOLT WITH A 5/16" WASHER.
3: SQUARE THE UPPER LEVEL CENTER POST TO THE DECK AND ATTACH THE BOTTOM OF
THE POST TO THE REAR BOTTOM PANEL BOARD WITH TWO #8 X 2-1/2" WOOD SCREWS.
REAR CENTER POST
5/16" X 2-1/2"
UPPER LEVEL
PANEL BOARD
HEX BOLT
UPPER LEVEL RAILING
5/16" WASHER
T-NUT
REAR BOTTOM
2 X 4 X 69-5/8"
#8 X 2-1/2"
WOOD SCREWS
