Gorilla Treasure Trove II User Manual

A
B
C
5/16 X 3-1/2"
LAG SCREW
D
5/16" WASHER
FRONT
OF
TOWER
5/4 x 4 x 36-11/16"
DECK BOARDS
2 X 4 X 36-3/4"
BOTTOM PANEL
BOARD (MAKE TOP OF BOARD
FLUSH WITH TOP OF DECK BOARDS)
STEP 9: FRONT FACE BOARD
1: PLACE THE 5/4 X 4 X 36-11/16" DECK BOARDS ON TOP OF THE DECK SUPPORTS. DO NOT FASTEN THE DECK
BOARDS AT THIS TIME.
2: PLACE THE 2 X 4 X 36-3/4" BOTTOM PANEL BOARD AGAINST THE FRONT CORNER POSTS, AND LEVEL THE TOP OF
THE BOARD WITH THE TOP OF THE DECK BOARDS.
3: FASTEN THE BOTTOM PANEL BOARD TO THE CORNER POSTS WITH 5/16 X 3-1/2" LAG SCREWS WITH 5/16"
WASHERS.
127
