5/4 X 4 X 29-3/8"
DECK SPACER
2X
"
1
"
8
"
4
3
3
"
4
1
3
4
1
3
4
"
1"
3"
4" 4"
4 X
1
8
"
BOTH ENDS WITH A 1/8" DRILL BIT USING THE DIMENSIONS SHOWN BELOW.
1: PRE-DRILL THE ENDS OF THE DECK SPACERS AND DECKBOARDS TO PREVENT INSTALLATION DAMAGE. PRE-DRILL
STEP 8: DECK BOARDS
SCREWS. NOTE THE TOP OF THE SCREW HEAD SHOULD BE FLUSH WITH THE TOP OF THE DECK SPACER.
THE FOLLOWING STEP IS RECOMMENDED TO PREVENT POSSIBLE SPLITS IN THE WOOD
THE INSIDE SURFACE OF THE 2 X 6. ATTACH EACH DECK SPACER TO THE DECK SUPPORTS WITH TWO 2" WOOD
2: PLACE THE 5/4 X 4 X 29-3/8" DECK SPACERS BETWEEN THE CORNER POSTS. MAKE EACH DECK SPACER FLUSH TO
5/4 X 4 X 36-1/2"
DECK BOARD
A
2 X 6 NOT SHOWN
B
HERE FOR CLARITY.
SCREW
C
INSIDE OF THE 2 X 6)
2" WOOD
D
BOTTOM PANEL
BOARD
5/4 X 4 X 29-3/8"
DECK SPACER
(MAKE FLUSH TO
2 X 6 X 36-3/4"
FRONT OF
TOWER
