Gorilla Treasure Trove II User Manual

STEP 36: UPPER LEVEL CENTER POST
1: PLACE THE 4 X 4 X 69-3/4" CENTER LAG POST UPPER LEVEL AGAINST THE 4 X 4 X 71-7/8"
REAR CENTER POST LOWER LEVEL. FLUSH THE SIDES OF THE POSTS TOGETHER.
2: ATTACH THE 4 X 4 X 69-3/4" CENTER LAG POST UPPER LEVEL TO THE 4 X 4 X 71-7/8" REAR
CENTER POST LOWER LEVEL WITH 3/8" X 5" LAG SCREWS AND 3/8" WASHERS.
3/8" X 5"
LAG SCREW
LOWER LEVEL
REAR CENTER POST
4 X 4 X 71-7/8"
UPPER LEVEL
CENTER LAG POST
4 X 4 X 69-3/4"
3/8"
WASHER
81
