Gorilla Treasure Trove II User Manual

STEP 61: TIC TAC TOE ASSEMBLY
1: LOCATE THE TIC TAC TOE BOX.
2: FOLLOW THE INSTRUCTIONS IN THE BOX TO ASSEMBLE THE TIC TAC TOE OMITTING STEPS
6 AND 7.
3: LOCATE TWO 5/4 X 3 X 17-1/2" TIC TAC TOE MOUNTS.
4: USE THE SCREWS INCLUDED WITH THE TIC TAC TOE TO ATTACH THE GREEN BRACKETS
TO THE TIC TAC TOE MOUNTS. EACH GREEN BRACKET SHOULD BE CENTERED OVER THE
TIC TAC TOE MOUNT.
TIC TAC TOE MOUNT
GREEN BRACKET
GREEN BRACKET
5/4 X 3 X 17-1/2"
TIC TAC TOE MOUNT
5/4 X 3 X 17-1/2"
TIC TAC TOE
AFTER ASSEMBLING.
106

Gorilla Treasure Trove II Specifications

General

Brand	Gorilla
Model	Treasure Trove II
Category	Play Sets & Playground Equipment
Language	English
