Gorilla Treasure Trove II User Manual

STEP 68: TELESCOPE
1: WITH THE 1-1/4" WOOD SCREWS PROVIDED IN THE TELESCOPE BAG, FASTEN ONE OF
THE SQUARE TELESCOPE BRACKETS TO THE ROPE LADDER SUPPORT ON THE ROCK WALL
SIDE OF THE CENTER POST.
2: PLACE THE TELESCOPE STAND AND TELESCOPE INTO THE SLOT OF THE TELESCOPE
BRACKET.
3: FASTEN THE REMAINING TELESCOPE BRACKET TO THE OPPOSITE SIDE THAT THE FIRST
TELESCOPE BRACKET WAS INSTALLED ON WITH 1-1/4" WOOD SCREWS PROVIDED WITH
THE TELESCOPE.
TELESCOPE STAND
TELESCOPE BRACKET
TELESCOPE
CENTER TARP SUPPORT
1-1/4" WOOD SCREW
113
