38
【Procedure of MLM measurement】
1. If considering the effect of grid scale you should
select menu item 1,else you should select menu
item 2;
2. Select one of two modes
3. Press F1:【Meas】to start EDM then you can
obtain the coordinates of the base point, or Press F3:
【Coor.】then you can call an existing coordinate
from current coordinate file.
4. the data of the base point is shown as the picture
on the left.
5. Press F1:【Meas】to start EDM then you can
obtain next coordinates, or Press F3:【Coor.】then
you can call an existing coordinate from current
coordinate file.
6. There are Dsd（slope distance）,Dhd（horizontal
distance）,Dvd（difference of height）and azimuth
attributes between two points. these attributes are
shown as the picture on the left.
–MLM–
1.MLM(A-B,A-C) ▲
2.MLM(A-B,B-C)
To Next Page
