Graco 24F150 User Manual

Parts
28 3A0732U
Package Parts 15:1 Ratio Pumps
Package Parts 15:1 Ratio Pumps
Ref.
No.
Description 24F150 24F151 24W281 24F158 24F159 24W283 24J250 24J251 24X311 Qty
1 BRACKET, wall 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 24H102 1
2 KIT, stand;
includes items
3, 4, 5, 6, and
43 below, and
418 on page 41
24F164 24F164 24F164 24F164 24F164 1
3 PLUG 108175 108175 108175 108175 108175 4
4 SCREW, cap,
hex hd; 1/4-20
x 1.5 in. (38
mm)
100058 100058 100058 100058 100058 6
5 SPACER, tube --- --- --- --- --- 4
6 NUT, hex;
1/4-20
100015 100015 100015 100015 100015 6
7 MOTOR, air;
see page 37
24G693 24G693 24G693 24G693 24G693 24G693 24G693 24G693 24G693 1
8 KIT, rod, tie;
includes rods
and items 11
and 17 (3 of
each)
24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 24G707 1
9 SPRING, safety 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 24H103 1
10 ADAPTER,
pump lower
24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 24H104 1
11 NUT, lock 104541 104541 104541 104541 104541 104541 104541 104541 104541 3
12 LOWER, pump;
see page 33;
also includes
items 15, 18,
and 19
24G701 24G701 24G701 24G702 24G702 24G702 24J121 24J121 24G701 1
13 NUT, jam 195150 195150 195150 195150 195150 195150 195150 195150 195150 1
15‡ NIPPLE; 1/4
npsm x 1/4 npt;
plated steel
162453 162453 162453 162453 162453 162453 1
NIPPLE; 1/4
npsm x 1/4 npt;
sst
166846 166846 166846 1
‡ Included in Pump Lower Rebuild Kit. See page 33.
* Not shown. See Merkur ES Hopper Kit manual 334011 for more information.
