Graco E-Flo SP - Page 33

Parts
3A6931A 33
D60 Ram Conversion Parts List
Quantity
Ref Part Description 25P280 25P281 25P282
101 25N519
KIT, driver, apd20, vertical
111
102
25N738 VALVE, check, 1 in. npt with relief
1
25N780 VALVE, check, 1 in.
1
25N739 VALVE, check, 1-1/2 in. npt
1
103 C38321 TIE, cable, 3.62 lg
221
104
131523 BUSHING, hex hd, 3/4 in. npt x 1 in. npt, ss
1
157191 FITTING, adapter, 1/2 in. npt x 3/4 in. npt
1
105 158586 FITTING, bushing
1
106 131524 FITTING, nipple, 1 in. npt, ss
1
107 131525 FITTING, nipple, reducing, ss
1
108 25E207 JUNCTION BOX, ram mounted, e-drive
111
109 16A314 BRACKET, mounting, acc. box, painted
111
110 15W703 BRACKET, mnting, btm, 3 in. ram, wld, pain
111
111 16A566 BRACKET, mounting, ram, wrmmlt, 3 in.
111
112 25E346 CABLE, track assembly, d60
111
113 100016 WASHER, lock
16 16 16
114 121112 SCREW, cap, socket head
12 12 12
115 100014 SCREW, cap, hex hd
444
116 100015 NUT, hex mscr
442
117 108050 WASHER, lock, spring
666
118 121518 SCREW, cap, shc
666
119 17X806PKG BRACKET, cable track, d60 ram, paint
111
120 255633 BRACKET, pendant pivot, painted
111
121 255639 BRACKET, mounting, assembly
111
122 110755 WASHER, plain
111
123 121250 SCREW, shcs, 1/4 unc x 4.25
111
124 117017 WASHER
111
125 121253 KNOB, display adj., ram pkgs
111
126 102040 NUT, lock, hex
111
127 255381 ACTUATOR, sensor, low/empty, painted
111
128 17Y702PKG BRACKET, lvl sensor, dual, d200, pnt
111
129 130787PKG SENSOR, barrel, m18 x 1, pnp, nc
111
130 123673 HARNESS
111
131 114958 STRAP, tie
444
132 110141 SCREW, cap, sch
444
133 100133 WASHER, lock, 3/8
444
134 102726 PLUG, pipe headles
111
135
15H392 ROD, adapter xtreme
11
15H371 ADAPTER, M38 x 2
1
136 15H370 ADAPTER, m38 x 2
1
137 16D782 BLANK, label, kit, 3 x 3
111
