Pressure Ratings
The APD20 electric driver provides approximately 30% more thrust than an NXT 3400 air motor. The table below
shows the pump working pressure and maximum dynamic pressure using the electric driver. The E-Flo SP Model
column shows the E-Flo model the system will be similar to when the conversion is complete. After converting the
system, follow all warnings and instructions for the E-Flo SP model listed instead of the previous air motor system.
For the pump lower size, CM is Check-Mate and DF is Dura-Flo.
To help prevent serious injury from skin injection, ver-
ify that any components downstream of the pump are
rated to the new, higher pressures shown in the table
below. Replace any components that are not rated to
the higher pressures.
Pump Working (Stall)
Pressure
Max Dynamic (Run)
Pressure
Kit No.
Pump
Lower Size
psi bar MPa psi bar MPa Ram Size
Air Motor
Size
E-Flo SP
Model
25P277 CM100 6000 414 41.4 6000 414 41.4 N/A
NXT 3400
EC100XX3
25P278
CM200, 4200 290 29.0 3905 269 26.9 N/A EC200XX3
CM250 3400 234 23.4 3122 215 21.5 N/A EC250XX3
DF115 6000 414 41.4 6000 414 41.4 N/A ED115XX3
DF145 5600 386 38.6 5204 359 35.9 N/A ED145XX3
DF180 4500 310 31.0 4164 287 28.7 N/A ED180XX3
DF220 3700 255 25.5 3470 239 23.9 N/A ED220XX3
DF290 2800 193 19.3 2602 179 17.9 N/A ED290XX3
25P279
CM500 1600 110 11.0 1487 103 10.3 N/A EC500XX3
DF430 1900 131 13.1 1735 120 12.0 N/A ED430XX3
25P280 CM100 6000 414 41.4 6000 414 41.4 D60
NXT3400
EMC11X3
25P281
CM200 4200 290 29.0 3905 269 26.9 D60 EMC51X3
CM250 3400 234 23.4 3122 215 21.5 D60 EMC91X3
DF115 6000 414 41.4 6000 414 41.4 D60 EMD11X3
DF145 5600 386 38.6 5204 359 35.9 D60 EMD21X3
DF180 4500 310 31.0 4164 287 28.7 D60 EMD41X3
DF220 3700 255 25.5 3470 239 23.9 D60 EMD61X3
DF290 2800 193 19.3 2602 179 17.9 D60 EMD81X3
25P282
CM500 1600 110 11.0 1487 103 10.3 D60 EMCD1X3
DF430 1900 131 13.1 1735 120 12.0 D60 EMDA1X3
25P283 CM100 6000 414 41.4 6000 414 41.4 D200 EMC12X3
