Parts
36 3A6931A
D200 Ram Conversion Parts List
Quantity
Ref Part Description 25P283 25P284 25P285
201 25N519
KIT, driver, apd20, vertical
111
202
25N738 VALVE, check, 1 in. npt with relief
1
25N780 VALVE, check, 1 in.
1
25N739 VALVE, check, 1-1/2 in. npt
1
203 C38321 TIE, cable, 3.62 lg
221
204
131523 BUSHING, hex hd, 3/4 in. npt x 1 in. npt, ss
1
157191 FITTING, adapter, 1/2 in. npt x 3/4 in. npt
1
205 158586 FITTING, bushing
1
206 131524 FITTING, nipple, 1 in. npt, ss
1
207 131525 FITTING, nipple, reducing, ss
1
208 25E207 JUNCTION BOX, ram mounted, e-drive
111
209 16A314 BRACKET, mounting, acc. box, painted
111
210 15W703 BRACKET, mnting, btm, 3 in. ram, wld, pain
111
211 16A566 BRACKET, mounting, ram, wrmmlt, 3 in.
111
212 25E347 CABLE, track assembly, d200
111
213 100016 WASHER, lock
16 16 16
214 121112 SCREW, cap, socket head
12 12 12
215 100014 SCREW, cap, hex hd
444
216 100015 NUT, hex mscr
444
217 108050 WASHER, lock, spring
666
218 121518 SCREW, cap, shc
666
219 17X808PKG BRACKET, cable track, d200 ram, paint
111
220 255633 BRACKET, pendant pivot, painted
111
221 255639 BRACKET, mounting, assembly
111
222 110755 WASHER, plain
111
223 121250 SCREW, shcs, 1/4 unc x 4.25
111
224 117017 WASHER
111
225 121253 KNOB, display adj., ram pkgs
111
226 102040 NUT, lock, hex
111
227 255381 ACTUATOR, sensor, low/empty, painted
111
228 17Y702PKG BRACKET, lvl sensor, dual, d200, pnt
111
229 130787PKG SENSOR, barrel, m18 x 1, pnp, nc
111
230 123656 CABLE, 5-pin, male/female, (matrix)
111
231 114958 STRAP, tie
444
232 110141 SCREW, cap, sch
444
233 100133 WASHER, lock, 3/8
444
234 102726 PLUG, pipe headles
111
235
15H392 ROD, adapter xtreme
11
15H371 ADAPTER, M38 x 2
1
236 15H370 ADAPTER, 1 1/4-12
1
237 16D782 BLANK, label, kit, 3 x 3
111
