TECHNICAL DATA
Power Requirements ............ ,230 VAC, 50Hz,
1 phase, 7 amp minimum
Working Pressure Range
............. 0 - 207 bar
Cycles/liter ................................ 53
Maximum Delivery
.................. 3.2 literlmin
Power Cord
............ No. 14 AWG, 3 wire, 2.6 m
Inlet Paint Strainer .................. 1190 micron
Stainless Steel Screen, reusable
Outlet Paint Filter
.................... 250 micron
Stainless Steel Screen. reusable
DIMENSIONS
Weight (dry w/o packaging) ........ 43 Kg (approx.)
Height
............................... 71 1 mm
Length ............................... 660mm
Width ................................ 572mm
Pump Inlet Size ..... 3/4 npt(m) with 20" ID chamfer
Fluid Outlet Size
.......... 1/4 npsm from fluid filter
Wetted Parts:
Displacement Pump
. . Carbon steel, Polyurethane,
UHMW polyethylene,
DelrinB, Leather
Filter .... Aluminum, Carbon steel, Stainless Steel,
NOTE: DelrinB
307 - 670 43

Graco E Series Specifications

General

Brand	Graco
Model	E Series
Category	Paint Sprayer
Language	English
