OPERATION
WITH THE TIP GUARD
REMOVED
NEVER OPERATE THE GUN
Fig
9
-
1
METAL TO METAL
CONTACT WHEN
FLUSHING
MAINTAIN FIRM
1
Fig
9
-
2
Cleaning
a
Clogged
Tip
WARNING
To reduce the risk of serious bodily injury from fluid
injection:
NEVER operate the spray gun with thetipguard re
-
moved.
DO
NOT hold your hand, body, or a rag in front of
the spray tip when cleaning or checking a clogged
tip. Always point
thegun toward the ground or into a
waste container when checking to see
if
the tip is
clear.
DO NOT
try
to
"
blow back" paint: this is NOT an air
mrav sDraver.
1.
Clean the front of the tip frequently during the day's
operation. First, follow the
Pressure Relief Proce
-
dure Warning
on page 8. Then use a solvent-
soaked
brush^
to wipe
-
away fluid build
-
up, which
helps prevent tip clogging.
2.
If the spray tip does clog, release the gun trigger, en
-
gage the gun safety latch, and rotate the RAC
IV
han
-
dle
180".
See
Fig
9
-
3.
3.
Disengage the gun safety latch and trigger the gun
into a waste container. Engage the gun safety latch
again.
4. Return the handle to the original position, disengage
the gun safety latch, and resume spraying,
5.
If the tip is still clogged, engage the gun safety latch,
shutoff and unplug the sprayer, and open the pres
-
tip as.shown in manual 307-848, supplied with the
sure drain valve to relieve pressure. Clean the spray
RAC IV.
RAC
IV
HANDLE SHOWN
IN SPRAYING POSITION,
DISENGAGES
TURN
HANDLElBO",
GUN
TO
CLEAR
LATCH AND TR
GUN
SAFETY
LATCH
SHOWN EN.
GAGED
Fig
9-3
307-670
9
