Parts
3A3489T
39
Enclosure Box Parts
WLD
Torque fitting with pump outlet fitting to 35–40 ft-lb (47.4–54.2 N•m).
Apply thread sealant to needle valve knob screw when reassembling. Align knob
with ‘D’ facing up when in closed position.
Apply thread sealant to selector valve handle set screw when reassembling.
1
3
4
38
40
