1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
12
03867
05107
05108
9a
9b
9c
L
9d
L
L
3Z7–615
Rev B
Supplement to instruction manual 307–615.
GH533
Hydra-Spray
R
Sprayer
INJECTION
HAZARD
This form is only a quick reference to the
features and frequently ordered parts of
this sprayer
. T
o reduce the risk of seri
-
ous injury
, including fluid injection, while operating
or repairing this sprayer
, follow the warnings and
instructions in manual 307–615.
INSTRUCTIONS
WARNING
Model 231–533, Series B
Ref
No.
Part No.
Description
1 218–717
Reservoir Kit
2
Y 185–951
Danger Label
3 217–022
Hydraulic Motor
4 217–504
Hydraulic Return Hose
5 217–468
Hydraulic Supply Hose
6 217–469 Frame
7 235–497
Check V
alve
8 214–570
Fluid Filter
9 217–530
Displacement Pump
9a 178–900 .Sleeve
9b 178–899
.Piston Rod
9c 205–516
.Piston V
alve
9d 217–476
.Intake V
alve
10 222–198
Pressure Drain V
alve
11 169–528
Suction T
ube
12 214–959
Suction Hose
13 217–284 Engine
14 106–063 Coupler
15 178–788 Cooler
16 178–873 V
ane Pump
Y
Extra danger labels are available for free.
Packing Repair Kit
220–399
Includes all parts marked with a
L
