Graco GrindLazer 270 Repair Manual

Table of Contents
2 3A0102D
Table of Contents
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Component Identification . . . . . . . . . . . . . . . . . . . . 5
Drum Replacement . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cutter Replacement . . . . . . . . . . . . . . . . . . . . . . . . . 7
Belt Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Clutch Replacement . . . . . . . . . . . . . . . . . . . . . . . 11
Pulley Replacement . . . . . . . . . . . . . . . . . . . . . . . . 12
Brush Replacement . . . . . . . . . . . . . . . . . . . . . . . . 13
Drive Bearing Assembly Replacement . . . . . . . . 14
Door Bearing Assembly Removal . . . . . . . . . . . 14
Door Bearing Assembly Installation . . . . . . . . . 14
Drive Bearing Assembly Removal . . . . . . . . . . 15
Drive Bearing Assembly Installation . . . . . . . . . 16
Sheave Installation . . . . . . . . . . . . . . . . . . . . . . 16
Cutter Stacking Recommendations . . . . . . . . . . . 17
6 in. (15 cm) Coarse Cut Flail Cutters (Double
Space)
276 Spacers / 60 Cutters . . . . . . . . . . . . . . 17
8 in. (20 cm) Coarse Cut Flail Cutters (Double
Space)
234 Spacers / 84 Cutters . . . . . . . . . . . . . . 18
10 in. (25 cm) Coarse Cut Flail Cutters (Double
Space)
210 Spacers / 102 Cutters . . . . . . . . . . . . . 19
6 in. (15 cm) General Cut Flail Cutters (Single
Space)
234 Spacers / 84 Cutters . . . . . . . . . . . . . . 20
8 in. (20 cm) General Cut Flail Cutters (Single
Space)
186 Spacers / 114 Cutters . . . . . . . . . . . . . 21
10 in. (25 cm) General Cut Flail Cutters (Single
Space)
150 Spacers / 138 Cutters . . . . . . . . . . . . . 22
6 in. (15 cm) Fine Cut Flail Cutters
198 Spacers / 108 Cutters . . . . . . . . . . . . . 23
8 in. (20 cm) Fine Cut Flail Cutters
138 Spacers / 144 Cutters . . . . . . . . . . . . . 24
10 in. (25 cm) Fine Cut Flail Cutters
90 Spacers / 174 Cutters . . . . . . . . . . . . . . 25
6 in. (15 cm) Cut Carbide Millers
204 Spacers / 30 Cutters . . . . . . . . . . . . . . 26
8 in. (20 cm) Cut Carbide Millers
132 Spacers / 42 Cutters . . . . . . . . . . . . . . 27
10 in. (25 cm) Cut Carbide Millers
66 Spacers / 54 Cutters . . . . . . . . . . . . . . . 28
6 in. (15 cm) Full Cut Flail Setup
258 Spacers / 84 Cutters . . . . . . . . . . . . . . 29
8 in. (20 cm) Full Cut Flail Setup
210 Spacers / 108 Cutters . . . . . . . . . . . . . 30
10 in. (25 cm) Full Cut Flail Setup
162 Spacers / 138 Cutters . . . . . . . . . . . . . 31
6 in. (15 cm) Steel Cutters Setup
222 Washers / 126 Cutters . . . . . . . . . . . . . 32
8 in. (20 cm) Steel Cutters Setup
156 Washers / 174 Cutters . . . . . . . . . . . . . 33
10 in. (25 cm) Steel Cutters Setup
114 Washers / 204 Cutters . . . . . . . . . . . . . 34
Diamond Blades . . . . . . . . . . . . . . . . . . . . . . . . 35
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 39
