Graco GrindLazer 270 Repair Manual

Cutter Stacking Recommendations
3A0102D 27
8 in. (20 cm) Cut Carbide Millers
132 Spacers / 42 Cutters
INSTRUCTIONS: Rotate sequence 180° and repeat for
remaining shafts.
(S) Spacer
(M) Miller
ti15056a
8 (S)
1 (S)
1 (M)
1 (M)
1 (S)
1 (M)
1 (S)
1 (M)
1 (S)
1 (M)
1 (S)
1 (S)
1 (M)
7 (S)
ti15051a
7 (S)
1 (M)
1 (M)
1 (M)
1 (M)
1 (M)
1 (M)
1 (S)
1 (S)
1 (S)
1 (S)
1 (S)
1 (S)
8 (S)
1 (M)
1 (S)
1 (M)
1 (S)
NOTE: Assembly may vary due to tolerances.
Stack cutters and spacers so the drum is properly
balanced to prevent excessive vibration.
